        XBS200-4 Bass shaker

        Xcite XBS200-4 Bass shaker

        €499,95

        1 In stock10+ expected on 30-04-2026

        Add to cart

        Xcite XBS200-4 Bass shaker

        0 reviews
        0 from 5
        0 reviews
        5 stars
        0%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: Xcite
        Show all New products
        200 W
        XBS200-4 Bass shaker
        XBS200-4 Bass shaker
        XBS200-4 Bass shaker
        XBS200-4 Bass shaker
        XBS200-4 Bass shaker
        XBS200-4 Bass shaker
        € 413,18€ 499,95 1 In stock10+ expected on 30-04-2026
        • -5% Purchase 4 for only € 474,95 per piece
        +-
        Add to cart

        Buy now, pay later

        • We ship to
        • Ordered now, shipped today
        • Five-year warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        XBS200-4 Bass shaker
        XBS200-4 Bass shaker
        XBS200-4 Bass shaker
        XBS200-4 Bass shaker
        XBS200-4 Bass shaker
        XBS200-4 Bass shaker

        Pros and cons

        According to our specialists
        • Extremely high peak force of 920 N
        • Compact: only 62mm high and 4.8 kg
        • High sensitivity: 16.1 N/W delivers strong output even with smaller amps
        • 1000W peak requires a power powerful amplifier to unlock full performance

        Product description Xcite XBS200-4 Bass shaker

        The New Standard in High-Definition Tactile Feedback



        Extreme force. Ultra-slim. Built for professional tactile systems.



        The Xcite XBS200 is the foundation for high-power installations, engineered for large-scale systems where maximum force and slim integration are critical. With 920 N peak force, ±15 mm excursion, and 16.1 N/W sensitivity, it delivers massive, efficient output with deep infrasonic impact and precise tactile separation across 10 Hz to 1 kHz.



        Optimized for structure—not furniture—the XBS200 injects controlled energy into platforms, risers, and heavy seating without sacrificing detail. Its high-flux neodymium motor ensures ultra-fast transient response, keeping signals clean and distinct even under extreme loads. 100% steel and aluminum construction. Double steel suspension. IP66-rated. Built for demanding environments.



        Designed in Germany.



        Highlights of the Xcite XBS200-4 Bass Shaker



        • Flat Force Frequency Response | Clear differentiation under multi-signal load — no more "signal mush".
        • 1000W Peak Power (IEC 60268-5) | Engineered for sustained high loads without thermal compression.
        • ±15 mm Xmax | Xtreme displacement for realistic, long-stroke structural movement.
        • 920 N Peak Force | Built to command heavy-duty installations and professional rigs.
        • 21 Hz Resonance Frequency | Extended infrasonic authority for impact you feel in your core.
        • Neodymium Motor + Oversized Coils | Instant, responsive impact with unmatched 16.1 N/W efficiency.
        • Double Steel Suspension | Industrial-grade durability; zero plastic fatigue.
        • Ultra-slim 62 mm Profile | Massive power that fits where other high-output units can’t.
        • IP66-rated | Ready for dust, moisture, and harsh professional environments.
        • High-Grade Aluminum Housing | Functions as a massive heat sink for consistent performance.
        • Minimal-footprint Terminals | Clean installation with zero added height or width.



        Product details Xcite XBS200-4 Bass Shaker



        Ready to Xcite you

        When a single unit is no longer the limit. The Xcite XBS200 is designed for installations where entire platforms, risers, or multi-seat structures become part of the tactile system. Its large moving mass (2590 g motor assembly) and extreme motor strength allow it to move heavy constructions with absolute precision.



        • Feel the foundation flex: True structural feedback for high-end simulators and VR-Training.
        • Synchronized Impact: Uniform energy distribution across platforms up to 15 m².
        • Subsonic Energy: Massive low-end rumble without distortion or mechanical noise.



        This is the Xcite XBS Series at maximum scale.



        SpiderCore Motor Architecture

        Here’s the Xcite advantage:



        Most transducers stack the suspension on top of the motor, increasing height and reducing maximum displacement. The XBS Series integrates the suspension directly into the motor core. The SpiderCore design makes the XBS up to 45% shorter than industry standards — enabling a truly ultra-slim profile without the typical loss of excursion or "bottoming out" common in flat designs.



        Even the terminals are engineered for minimal footprint, adding no unnecessary height or width. Ultra-slim engineering — with full excursion, extreme output, and durability.



        Installation Recommendation

        • Industrial-Grade Install: Secure with 4 high-tensile screws to a rigid frame or platform.
        • Recommended Amp: 200–1000 W @ 4 Ohm. The extreme 16.1 N/W sensitivity ensures massive output even on mid-range amplifiers.
        • Suggested Low-Pass: 100 Hz (Impact focus) up to 150 Hz (Detail focus).
        • Versatile Mounting: Symmetric internal suspension allows mounting in any orientation (vertical, inverted, or sideways).



         System Configuration Guidance

        • Home Cinema: 1–2x per heavy seat | 1–4x per large couch or riser.
        • Platform Installation: 1x unit for platforms from 0.5 m² up to 15 m².
        • Sim Racing Pro: The ultimate engine for full rig excitation.





        Is the XBS200 right for you?

        • You want maximum output in minimal space
        • You want true immersive bass — not just a shake
        • You want full-range tactile feedback — not a single rumble note
        • You care about long-term reliability — only steel and aluminum, no plastic
        • You demand precision — the ultra-light motor responds instantly
        • You need hardware that thrives in harsh environments



        If your installation requires uncompromising force and High-Definition tactile feedback in a compact profile, the XBS200 is your foundation engine.



        A basic guide to creating invisible sound with exciters

        Curious about how bass shakers work and why they are so popular? In this blog, we share in-depth knowledge, give hardware/software recommendations and share the most important information about using bass shakers within the most popular applications. An indispensable resource for the passionate DIY audio enthusiast.

        Show more

        Specifications

        Article number
        XBS200-4
        EAN
        9504546768468
        Power Handling (RMS)
        200 Watts
        Power Handling (max)
        1.000 Watts
        Impedance
        4 Ω
        Frequency Response
        10 - 100 Hz
        Resonant Frequency (Fs)
        21.1 Hz
        DC Resistance (Re)
        4.08 Ω
        Voice Coil Inductance (Le)
        0.83 mH
        Total Q (Qts)
        1.41
        Diaphragm Mass Inc. Airload (Mms)
        2590 G
        BL Product (BL)
        29.1 N/A
        Voice Coil Diameter
        178 mm
        Overall Outside Diameter
        230 mm
        Overall Depth
        62 mm
        # Mounting Holes
        4
        Mounting type
        Screws 6.3 mm
