Scan-Speak Discovery D7608/920010 3" Mid Dome

Delivery time: 1-4 business days

  • Article code: D7608/920010
  • Stock: 4 In stock

The Discovery series offer traditional design, superior sound, a solid construction, and a wide range of variants. Combining these elements - plus a wealth of technical features and finesses - it gives our customers the possibility of acquiring a tailor-m

€ 88,45 Incl. 21% VAT

  • Buy 4 for €84,03 each and save 5% Sale 5%

Add to wishlist

  • Low international shipping rates Tooltip

    Find all shipping rates and free shipping thresholds here

  • Same day shipping
  • 45-day money back guarantee
  • International payment options

Product description

Scan-Speak Discovery D7608/920010 3" Mid Dome

Highlights

  • Fast action due to low moving mass
  • High SPL Output 92dB
  • Internal Ferrite Magnet
  • Wide Dispersion
  • Vented / open rearside (requires chamber)
  • Internal grill to prevent dome from being pushed in



Product Details

Scan-Speak Discovery D7608/920010 3" Mid Dome



The Discovery series offer traditional design, superior sound, a solid construction, and a wide range of variants. Combining these elements - plus a wealth of technical features and finesses - it gives our customers the possibility of acquiring a tailor-made Scan-Speak solution with very good performance at a reasonable low price point!



This speaker is known to be a good replacement for Infinity Kappa series 7, 8 and 9.

Specifications

Specifications for: Discovery D7608/920010 3" Mid Dome

  • Woofer Series Specific woofer production line of the manufacturer. Discovery Series
  • Woofer Type The driver type for example subwoofer, mid-woofer, full range or coaxial woofer. mid-dome
  • Nominal Diameter The approximate diameter of the driver, measured in inches. 3"
  • Power Handling (RMS) The average power handling capability of a driver (coil) in electric power (watts) for a long period of time without damaging the driver. RMS stands for Root Mean Square 80 Watts
  • Power Handling (max) The maximum electrical power that a woofer (coil) can handle for a short period of time before it is damaged.
  • View all specifications
  • Continuous Program Power
  • Impedance 8 ohms
  • Sensitivity 92 dB 2.83V/1m
  • Frequency Response
  • Voice Coil Diameter 2.99"
  • Magnet Weight
  • DC Resistance (Re) 5.7 ohms
  • Voice Coil Inductance (Le) 0.13 mH
  • Resonant Frequency (Fs) 300 Hz
  • Mechanical Q (Qms) 7.75
  • Electromagnetic Q (Qes) 2.22
  • Total Q (Qts) 1.73
  • Diaphragm Mass Inc. Airload (Mms) 3.3g
  • Moving Mass Of Diaphragm (Mmd)
  • Mechanical Compliance of Suspension (Cms) 0.09 mm/N
  • Surface Area of Cone (Sd) 55 cm2
  • Volume of Displacement (Vd)
  • BL Product (BL) 4.7 Tm
  • Compliance Equivalent Volume (Vas) 0.01 ft.³
  • Maximum Linear Excursion (Xmax) 0.4 mm
  • Driver's Mechanical Losses (Rms)
  • Cone / Diaphragm Material
  • Surround Material
  • Voice Coil Wire Material
  • Voice Coil Former
  • Dual Voice Coil
  • Basket / Frame Material
  • Magnet Material
  • Shielded
  • Overall Outside Diameter
  • Overall Depth
  • Baffle Cutout Diameter
  • Bolt Circle Diameter
  • # Mounting Holes
  • Mounting Hole Diameter
  • Sealed Volume
  • Sealed F3
  • Vented Volume
  • Vented F3

Documenten

Reviews

User reviews 5 / 5 Reviews: (2)

  • AS By Andreas S. on 13-03-2020 15:09

    5 / 5

    Ein sehr guter Lautsprecher. Vor allem bei dem Preis.

  • HD By Heinz D. on 13-11-2019 10:55

    5 / 5

    Idealer Ersatz für den nicht mehr erhältlichen Mitteltöner zur Infinity Kappa 7.
