- Article number
- 10F/8424G00
- EAN
- 8785256848324
- Woofer Series
- Discovery
- Woofer Type
- Fullrange
- Nominal Diameter
- 78 mm
- Power Handling (RMS)
- 15 Watt
- Power Handling (max)
- 30 Watt
- Impedance (Z)
- 8 Ohm
- Sensitivity (SPL at 1m / 2.83V)
- 86.5 dB
- Frequency Response
- 150-12000 Hz
- Voice Coil Diameter
- 20 mm
- DC Resistance (Re)
- 5.8 Ohm
- Voice Coil Inductance (Le)
- 0.13 mH
- Resonant Frequency (Fs)
- 90 Hz
- Mechanical Q (Qms)
- 3.49
- Electromagnetic Q (Qes)
- 0.41
- Total Q (Qts)
- 0.37
- Diaphragm Mass Inc. Airload (Mms)
- 2.77 g
- Mechanical Compliance of Suspension (Cms)
- 1.13 mm/N
- Surface Area of Cone (Sd)
- 36 cm2
- BL Product (BL)
- 4.8 Tm
- Compliance Equivalent Volume (Vas)
- 2.1 L
- Maximum Linear Excursion (Xmax)
- 7 mm
- Driver's Mechanical Losses (Rms)
- 0.45 kg/s
- Voice Coil Wire Material
- Fibre Glass
- Basket / Frame Material
- Aluminium
- Overall Outside Diameter
- 97.5 mm
- Overall Depth
- 40 mm
- Baffle Cutout Diameter
- 78 mm
- Vented Volume
- 1.9 Litres
