Peerless by Tymphany XXLS-P835017 12" Aluminum Cone XXLS Subwoofer

1 reviews

Brand: Peerless by Tymphany

Show all Subwoofer

Compare

12" | 4 Ω

XXLS-P835017 12" Aluminum Cone XXLS Subwoofer

€ 226,41€ 273,95 Out of stock: please contact us for accurate delivery times

Backorder

24h express shipping available
Same day shipping
In-house techniscal support
45 days worry-free returns

Do you have a question about this product?

Our employee is happy to help you find the right product

Product description

This series of state-of-the-art subwoofers continues to enhance Peerless's reputation for delivering the highest quality components for bass.

Highlights

12.5 mm of linear excursion
Extremely durable aluminum cone
Cast aluminum frame
Flat spider and HD rubber half roll surround
Massive stacked magnet

Product details

Peerless by Tymphany XXLS-P835017 12" Aluminum Cone XXLS Subwoofer

This 12 inch 4 ohm member of the XXLS product family has all the design features suitable for a high performance, high excursion subwoofer driver. The motor features a double ferrite magnet motor, supporting high excursion, and aluminium shorting rings and pole extenders, lowering and linearizing the inductance of the overhung voice coil. The Aluminium cone is vented under the dust cap, to reduce air compression. The suspension system features a low-creep rubber surround, and a nomex spider, ensuring long-term reliability under high power conditions. The product also features a rigid cast aluminium basket.

Specifications

Article number: XXLS-P835017
Woofer Series: XXLS Series
Woofer Type: Subwoofer
Nominal Diameter: 12"
Power Handling (RMS): 175 Watts
Power Handling (max): 350 Watts
Impedance (Z): 4 Ohms
Sensitivity: 88.6 dB 2.83V/1m
Frequency Response: 19 to 1,000Hz
Voice Coil Diameter: 2"
DC Resistance (Re): 2.5 ohms
Voice Coil Inductance (Le): 0.53 mH
Resonant Frequency (Fs): 22 Hz
Mechanical Q (Qms): 10.83
Electromagnetic Q (Qes): 0.4
Total Q (Qts): 0.39
Diaphragm Mass Inc. Airload (Mms): 131.4g
Mechanical Compliance of Suspension (Cms): 0.42 mm/N
Surface Area of Cone (Sd): 483.1 cm²
BL Product (BL): 10.58 Tm
Compliance Equivalent Volume (Vas): 4.8 ft.³
Maximum Linear Excursion (Xmax): 12.5 mm
Cone / Diaphragm Material: Aluminium
Surround Material: Rubber
Basket / Frame Material: Cast Aluminum
Magnet Material: Ferrite
Overall Outside Diameter: 12.12"
Overall Depth: 6.38"
Baffle Cutout Diameter: 10.91"
# Mounting Holes: 6
Sealed Volume: 1.04 ft.³
Sealed F3: 49 Hz
Vented Volume: 2.64 ft.³
Vented F3: 29 Hz

Data sheet

Reviews

1 reviews

4 from 5Based on 1 reviews

Review this product

4 of 5

Geringe Leistungsaufnahme, gute Performance. Sehr Tief. Bald werde ich das DBA von 2x2 auf 2x4 erweitern. Da Sie momentan auf Anschlag laufen wenn die Dolby LF-Kanal reinfeuert

By Mathias B. on 7 May 2020
