        HDS-P830991 5-1/4" GFC Cone HDS Woofer

        Peerless by Tymphany HDS-P830991 5-1/4" GFC Cone HDS Woofer

        €54,95

        10+ In stock

        Add to cart

        Peerless by Tymphany HDS-P830991 5-1/4" GFC Cone HDS Woofer

        0 reviews
        0 from 5
        0 reviews
        5 stars
        0%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: Peerless by Tymphany
        Show all Peerless by Tymphany woofers
        5¼" | 8 Ω
        HDS-P830991 5-1/4" GFC Cone HDS Woofer
        HDS-P830991 5-1/4" GFC Cone HDS Woofer
        HDS-P830991 5-1/4" GFC Cone HDS Woofer
        HDS-P830991 5-1/4" GFC Cone HDS Woofer
        HDS-P830991 5-1/4" GFC Cone HDS Woofer
        HDS-P830991 5-1/4" GFC Cone HDS Woofer
        € 45,41€ 54,95 10+ In stock
        • -5% Purchase 4 for only € 52,20 per piece
        +-
        Add to cart

        Buy now, pay later

        • We ship to
        • Ordered now, shipped on Monday
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        HDS-P830991 5-1/4" GFC Cone HDS Woofer
        HDS-P830991 5-1/4" GFC Cone HDS Woofer
        HDS-P830991 5-1/4" GFC Cone HDS Woofer
        HDS-P830991 5-1/4" GFC Cone HDS Woofer
        HDS-P830991 5-1/4" GFC Cone HDS Woofer
        HDS-P830991 5-1/4" GFC Cone HDS Woofer

        Product description Peerless by Tymphany HDS-P830991 Bass-midwoofer

        The Peerless High Definition Sound (HDS) Series offers high-quality solutions for multi-way speaker systems employing vented box alignments.



        Highlights

        • Truncated cast aluminum frame
        • Glass-Fibre Composite (GFC) cone with half-roll rubber surround
        • Long-throw voice coil
        • Shorting rings for reduced distortion
        • Under-spider and voice coil ventilation



        Product details

        Peerless by Tymphany HDS-P830991 5-1/4" GFC Cone HDS Woofer



        This 5.25 inch 8 ohm driver is a member of the high performance HDS family. A powerful ferrite magnet system is coupled to a finite element analysis designed suspension system, containing both a linear spider design and a rubber surround. The motor contains an aluminium shorting ring, which reduces coil inductance, thus providing both extended frequency response performance and reduced distortion. The long-throw voice coil ensures linear high excursion performance, needed for signal clarity. The cone necks are vented so as to reduce air compression effects under high excursion conditions. The cast aluminium basket offers structural rigidity, heat sinking capacity for the motor, and additional air venting under the spider so as to again reduce air compression effects. The cone in this model is a glass fibre composite, offering a unique visual and acoustic experience.

        Show more

        Specifications

        Article number
        HDS-P830991
        EAN
        0844632083983
        Woofer Series
        Peerless by Tymphany HDS series
        Woofer Type
        Midwoofer
        Nominal Diameter
        5.25 "
        Power Handling (RMS)
        30 Watts
        Impedance (Z)
        8 Ω
        Sensitivity (SPL at 1m / 2.83V)
        86.4 dB
        Frequency Response
        100 - 4000 Hz
        Voice Coil Diameter
        25.7 mm
        DC Resistance (Re)
        5.9 Ω
        Voice Coil Inductance (Le)
        0.352 mH
        Resonant Frequency (Fs)
        76 Hz
        Mechanical Q (Qms)
        2.64
        Electromagnetic Q (Qes)
        0.692
        Total Q (Qts)
        0.55
        Diaphragm Mass Inc. Airload (Mms)
        9.83 g
        Mechanical Compliance of Suspension (Cms)
        450 μm/N
        Surface Area of Cone (Sd)
        89.9 cm²
        BL Product (BL)
        6.35 Tm
        Compliance Equivalent Volume (Vas)
        5.11 L
        Maximum Linear Excursion (Xmax)
        7.65 mm
        Cone / Diaphragm Material
        Fiberglass
        Surround Material
        Rubber
        Basket / Frame Material
        Cast Aluminum
        Magnet Material
        Ferrite
        Overall Outside Diameter
        Ø 152 x 134 mm
        Overall Depth
        70 mm
        Baffle Cutout Diameter
        121 mm
        Bolt Circle Diameter
        140 mm
        # Mounting Holes
        6
        Mounting Hole Diameter
        5 mm

        Show more
