        Monacor SPM-200X/4 8'' Full Range Driver 4 Ohm

        1 reviews
        5 from 5
        1 reviews
        5 stars
        100%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: Monacor
        € 35,50€ 42,95 5 In stock
        • -5% Order 4 for only € 40,80 per piece

        Buy now, pay later

        • We ship to
        • Ordered now, shipped on Monday
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        Product description

        A very high efficiency full range woofer with improved high frequency dispersion thanks to the whizzer cone and therefore a jack of all trades; should it be PA, home audio or instrument amplification.



        Highlights

        • Very high efficiency
        • Very linear frequency response
        • Improved high frequency dispersion thanks to the whizzer cone



        Product details

        Monacor SPM-200X/4 8'' Full Range Driver 4 Ohm



        The Monacor SPM-200X/4 is a high efficiency 8’’ full range driver with a surprisingly linear response. Furthermore it exhibits all the positive characteristics of a full range speaker, such as the point source reproduction, with reduced beaming in the highs thanks to the well-integrated whizzer cone: The best of both worlds!



        Its incredibly high efficiency makes it an ideal PA woofer but it is also very well suited for home audio purposes, especially high efficiency point source speaker systems. In both cases subwoofer support is required for the complete experience

        Show more

        Specifications

        Article number
        SPM-200X/4
        Woofer Type
        Full-Range
        Nominal Diameter
        8''
        Power Handling (RMS)
        30 Watts
        Power Handling (max)
        60 Watts
        Impedance (Z)
        4 Ohms
        Sensitivity
        94 dB 1W/m
        Frequency Response
        89-20,000Hz
        Voice Coil Diameter
        25 mm
        DC Resistance (Re)
        3.7 Ohms
        Voice Coil Inductance (Le)
        0.2 mH
        Resonant Frequency (Fs)
        89 Hz
        Mechanical Q (Qms)
        2.69
        Electromagnetic Q (Qes)
        1.52
        Total Q (Qts)
        0.97
        Diaphragm Mass Inc. Airload (Mms)
        9.9 g
        Mechanical Compliance of Suspension (Cms)
        0.27 mm/N
        Surface Area of Cone (Sd)
        201 cm2
        BL Product (BL)
        3.90 Tm
        Compliance Equivalent Volume (Vas)
        14.9 l
        Maximum Linear Excursion (Xmax)
        1 mm
        Cone / Diaphragm Material
        Paper
        Surround Material
        Cloth
        Voice Coil Wire Material
        Copper
        Voice Coil Former
        Aluminum
        Basket / Frame Material
        Stamped steel
        Magnet Material
        Ferrite
        Overall Outside Diameter
        205 mm
        Overall Depth
        82 mm
        Baffle Cutout Diameter
        184 mm
        # Mounting Holes
        4
        Mounting Hole Diameter
        5 x 8 mm

        Show more

        5 of 5
        Ik heb deze speakers gekocht voor het moderniseren van een Vintage radio. Vanwege de open achterzijde van de radio. moest ik kiezen voor een speaker met een hoge Qts waarde. Deze speaker voldeed aan deze voorwaarde. Aangesloten op het meebestelde Arylyc 2.1 kaartje. Ik ben zeer tevreden over het resultaat. Echt heel goed geluid voor dat geld !
        By Remi W. on 19 May 2021
