        W 250 S - 8 10" HiFi Woofer 8 Ohm

        W 250 S - 8 10" HiFi Woofer 8 Ohm

        €89,95

        Visaton W 250 S - 8 10" HiFi Woofer 8 Ohm

        0 reviews
        0 from 5
        0 reviews
        5 stars
        0%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: Visaton
        € 74,34€ 89,95 3 In stock
        • -5% Purchase 4 for only € 85,45 per piece

        Buy now, pay later

        • We ship to
        • Ordered now, shipped today
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        Product description

        The W 250 S 10" woofer from Visaton delivers amazing performance not normally found in drivers this size at this price point. A low Qts allows you to get very deep bass in a reasonably sized ported enclosure.



        Highlights

        • Very flat frequency response for easy system integration
        • Great for use as a HiFi woofer or as a subwoofer
        • Great sensitivity combined with low Fs and Qts for high performance



        Product details

        Visaton W 250 S 10" HiFi Woofer 8 Ohm



        This woofer features a coated paper cone, durable rubber surround, and a bumped back plate to an excursion limit of ±7 mm. A balanced design approach between sensitivity, smooth frequency response (cross it over as high as 2,500 Hz), and extended bass allows this driver to be used as a high-output HiFi woofer in three-way speaker systems or as a subwoofer.



        Visaton article code: 9034

        Show more

        Specifications

        Article number
        W 250 S - 8
        Woofer Series
        HiFi Series
        Woofer Type
        Midwoofer
        Nominal Diameter
        10"
        Power Handling (RMS)
        100 Watts
        Power Handling (max)
        150 Watts
        Impedance (Z)
        8 ohms
        Sensitivity (SPL at 1m / 2.83V)
        90 dB
        Frequency Response
        31 - 5,500 Hz
        Voice Coil Diameter
        38 mm
        DC Resistance (Re)
        6.6 ohms
        Voice Coil Inductance (Le)
        1.5 mH
        Resonant Frequency (Fs)
        31 Hz
        Mechanical Q (Qms)
        1.88
        Electromagnetic Q (Qes)
        0.39
        Total Q (Qts)
        0.32
        Diaphragm Mass Inc. Airload (Mms)
        38g
        Surface Area of Cone (Sd)
        346 cm2
        BL Product (BL)
        9.2 Tm
        Compliance Equivalent Volume (Vas)
        121 liters
        Maximum Linear Excursion (Xmax)
        5 mm
        Cone / Diaphragm Material
        Treated Paper
        Surround Material
        Rubber
        Overall Outside Diameter
        283 mm
        Overall Depth
        120 mm
        Baffle Cutout Diameter
        233 mm
        Bolt Circle Diameter
        267 mm
        # Mounting Holes
        5
        Sealed Volume
        22.7 liters
        Sealed F3
        76 Hz
        Vented Volume
        46.7 liters
        Vented F3
        47 Hz

        Show more
