        W 170 S - 8 6.5" HiFi Woofer 8 Ohm

        W 170 S - 8 6.5" HiFi Woofer 8 Ohm

        €43,95

        Visaton W 170 S - 8 6.5" HiFi Woofer 8 Ohm

        3 reviews
        5 from 5
        3 reviews
        5 stars
        67%
        4 stars
        33%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: Visaton
        € 36,32€ 43,95 Out of stock6 expected on 05-04-2024
        • -5% Purchase 4 for only € 41,75 per piece

        Buy now, pay later

        • We ship to
        • Ordered now, shipped today
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        Product description

        17 cm (6.5") HiFi woofer with coated paper cone, powerful drive and extended rear pole plate.



        Highlights

        • Extremely well balanced woofer
        • Easy to design into many different speaker systems
        • Foam surround and ribbed paper cone for a classic sound



        Product details

        Visaton W 170 S 6,5" HiFi Woofer 8 Ohm



        This woofer features a coated paper cone, durable rubber surround, and a bumped back plate to allow for an excursion limit of ±10 mm. A very balanced and extended frequency response allows the W 170 S to be used as a woofer in small two-way speakers or a midbass/midrange in three-way speakers, with a crossover point as high as 6,800 Hz, or even as a small form-factor subwoofer! This allows you to build a surround sound system with large speakers for front and left, while maintaining the same voicing in smaller surround satellite speakers.



        Visaton article code: 9025

        Show more

        Specifications

        Article number
        W 170 S - 8
        Woofer Series
        HiFi Series
        Woofer Type
        Midwoofer
        Nominal Diameter
        6.5"
        Power Handling (RMS)
        50 Watts
        Power Handling (max)
        80 Watts
        Impedance (Z)
        8 ohms
        Sensitivity (SPL at 1m / 2.83V)
        86 dB
        Frequency Response
        36 - 8,000 Hz
        Voice Coil Diameter
        25 mm
        DC Resistance (Re)
        5.9 ohms
        Voice Coil Inductance (Le)
        1.2 mH
        Resonant Frequency (Fs)
        36 Hz
        Mechanical Q (Qms)
        2.43
        Electromagnetic Q (Qes)
        0.66
        Total Q (Qts)
        0.52
        Diaphragm Mass Inc. Airload (Mms)
        13g
        Surface Area of Cone (Sd)
        129 cm2
        BL Product (BL)
        5.4 Tm
        Compliance Equivalent Volume (Vas)
        38 liters
        Maximum Linear Excursion (Xmax)
        4.25 mm
        Cone / Diaphragm Material
        Treated Paper
        Surround Material
        Rubber
        Overall Outside Diameter
        187.3 mm
        Overall Depth
        81 mm
        Baffle Cutout Diameter
        148 mm
        Bolt Circle Diameter
        175.8 mm
        # Mounting Holes
        5
        Mounting Hole Diameter
        4.4 mm
        Sealed Volume
        26.6 liters
        Sealed F3
        55 Hz
        Vented Volume
        65.4 liters
        Vented F3
        26 Hz
