      Visaton TIW 200 XS 8" High-End Woofer 8 Ohm

      € 132,19€ 159,95 2 In stock: delivery time 1-4 business days
      Bulk discount Enjoy these awesome discount deals
      • -5% Order 4 for only € 151,95 per piece
      • 24h express shipping available
      • Same day shipping
      • In-house techniscal support
      • 45 days worry-free returns
      Do you have a question about this product?

      Do you have a question about this product?

      Our employee is happy to help you find the right product

      Product description

      20 cm (8") High-end woofer specially for use as a small subwoofer.



      Highlights

      • Rigid Sandwich diaphragm
      • Wide surround
      • Long voice coil



      Product details

      Visaton TIW 200 XS 8" High-End Woofer



      The extra-wide elastic surround, the long voice coil and particularly large magnet arrangement give this speaker extremely long excursion. Thanks to the multiple venting of the voice coil (pole piece hole, holes in the pole piece plate, cutouts in the aluminium diecast cone to vent the centering unit from behind) losses and flow noise are minimised. The capton voice coil carrier and the long voice coil enable the driver to withstand considerable loads. The diaphragm is a sandwich construction made up of layers of fibreglass and polyester fabric which makes it particularly rigid and low in resonance. These design features result in high level accuracy and excellent low-range bass imaging even in smaller cabinets.

      Specifications

      Article number
      TIW 200 XS
      Woofer Series
      High-End
      Woofer Type
      Midwoofer
      Nominal Diameter
      222 mm
      Power Handling (RMS)
      120 Watts
      Power Handling (max)
      120 Watts
      Impedance (Z)
      8 ohms
      Sensitivity
      84 dB (1 W/1 m)
      Frequency Response
      30 - 7,500 Hz
      Voice Coil Diameter
      38 mm
      DC Resistance (Re)
      6 ohms
      Voice Coil Inductance (Le)
      1.6 mH
      Resonant Frequency (Fs)
      30 Hz
      Mechanical Q (Qms)
      5.19
      Electromagnetic Q (Qes)
      0.5
      Total Q (Qts)
      0.46
      Diaphragm Mass Inc. Airload (Mms)
      33g
      Surface Area of Cone (Sd)
      206 cm2
      BL Product (BL)
      8.51 Tm
      Compliance Equivalent Volume (Vas)
      51.5 liters
      Maximum Linear Excursion (Xmax)
      11 mm
      Cone / Diaphragm Material
      Fiberglass Polyester Sandwich
      Voice Coil Former
      Kapton
      Basket / Frame Material
      Cast Aluminum
      Overall Outside Diameter
      222 mm
      Overall Depth
      114
      Baffle Cutout Diameter
      190 mm
      Bolt Circle Diameter
      210 mm
      # Mounting Holes
      6
      Mounting Hole Diameter
      5 mm

      Show more
