- Article number
- GF 200
- Woofer Series
- High-End
- Woofer Type
- Midwoofer
- Nominal Diameter
- 8"
- Power Handling (RMS)
- 120 watts
- Power Handling (max)
- 180 watts
- Impedance
- 2x4 ohms
- Sensitivity
- 85 - 88 dB (1 W/1 m)
- Frequency Response
- 30 - 4,000 Hz
- Voice Coil Diameter
- 38 mm
- DC Resistance (Re)
- 1.4 - 5.8 ohms
- Voice Coil Inductance (Le)
- 0.3 - 1.1 mH
- Resonant Frequency (Fs)
- 30 Hz
- Mechanical Q (Qms)
- 4.12 - 4.51
- Electromagnetic Q (Qes)
- 0.37 - 0.93
- Moving Mass Of Diaphragm (Mmd)
- 25g
- Surface Area of Cone (Sd)
- 214 cm2
- BL Product (BL)
- 4.6 - 9.2 Tm
- Compliance Equivalent Volume (Vas)
- 57 - 68 liters
- Maximum Linear Excursion (Xmax)
- 6 mm
- Cone / Diaphragm Material
- Fiberglass
- Surround Material
- Rubber
- Voice Coil Former
- Kapton
- Dual Voice Coil
- Yes
- Basket / Frame Material
- Cast Aluminum
- Overall Outside Diameter
- 222 mm
- Overall Depth
- 96 mm
- Baffle Cutout Diameter
- 190 mm
- Bolt Circle Diameter
- 210 mm
- # Mounting Holes
- 6
- Mounting Hole Diameter
- 5 mm
