Visaton B 80 3.3" High-End Full-Range Loudspeaker 8 Ohm

Name: Visaton B 80 3.3" High-End Full-Range Loudspeaker 8 Ohm
Brand: Visaton
SKU: B 80
Price: 71.95 EUR
Availability: BackOrder
Rating: 5 (2 reviews)

2 reviews

Brand: Visaton

Show all Full-range woofer

Compare

3.3" | 8 Ω

B 80 3.3" High-End Full-Range Loudspeaker 8 Ohm

€ 59,46€ 71,95 Out of stock: please contact us for accurate delivery times

Backorder

24h express shipping available
Same day shipping
In-house techniscal support
45 days worry-free returns

Do you have a question about this product?

Our employee is happy to help you find the right product

Product description

8 cm (3.3") high-end full-range loudspeaker with excellent balanced response characteristics.

Highlights

Low mechanical losses
Great for small high-end applications
Balanced response characteristics

Product details

Visaton B 80 3.3" High-End Full-Range Loudspeaker 8 Ohm

Due to perfect accordance of the coated paper cone, the rear ventilated damper and the phase plug, as well as the strong and lightweight neodymium magnet, an extremely well-balanced frequency response with very low harmonic distortion and lowest possible mechanical losses comes into being. The B 80 woofer is ideal for small high-end shelf speakers or as a mid-high-range unit in high-end multi-way speakers.

Specifications

Article number: B 80
Woofer Series: High-End
Woofer Type: Full-Range
Nominal Diameter: 3.3"
Power Handling (RMS): 30 Watts
Power Handling (max): 50 Watts
Impedance (Z): 8 ohms
Sensitivity: 85 dB (1 W/1 m)
Frequency Response: 80 - 20,000 Hz
Voice Coil Diameter: 25 mm
DC Resistance (Re): 6.6 ohms
Resonant Frequency (Fs): 110 Hz
Mechanical Q (Qms): 6.53
Electromagnetic Q (Qes): 0.69
Total Q (Qts): 0.63
Mechanical Compliance of Suspension (Cms): 0.87 mm/N
Surface Area of Cone (Sd): 38.5 cm2
BL Product (BL): 4.15 Tm
Maximum Linear Excursion (Xmax): 2.25 mm
Cone / Diaphragm Material: Treated Paper
Surround Material: Rubber
Overall Outside Diameter: 104.4 mm
Overall Depth: 49.3 mm
Baffle Cutout Diameter: 89 mm
Bolt Circle Diameter: 95 mm
# Mounting Holes: 4
Mounting Hole Diameter: 3.9 mm

Data sheet

Reviews

2 reviews

5 from 5Based on 2 reviews

Review this product

5 of 5

Deze Visaton B80 zijn kleine geweldenaartjes! Ik heb ze in een transmission line kast gemonteerd als vervanging van (door een ongelukje defect geraakte) Vifa speakers. Na een inspeelperiode en corrigeren van het correctie netwerk spelen ze geweldig! Mooi gedetailleerd, laag reikend en toch nog dynamisch geluid. Oké, het rendement is laag, maar met een nette versterker er aan kunnen ze toch verrassend luid spelen, zonder dat het geluid dicht slibt. Een echt aanrader!

By Tjeerd on 1 June 2022

5 of 5

No description was given

By Andrea S. on 29 May 2020
