Visaton B 100 4" High-End Full-Range Loudspeaker 6 Ohm

Name: Visaton B 100 4" High-End Full-Range Loudspeaker 6 Ohm
Brand: Visaton
SKU: B 100
Price: 88.45 EUR
Availability: InStock
Rating: 4.5 (2 reviews)

2 reviews

Brand: Visaton

Show all Full-range woofer

Compare

4" | 6 Ω

B 100 4" High-End Full-Range Loudspeaker 6 Ohm

€ 73,10€ 88,45 2 In stock: delivery time 1-4 business days

24h express shipping available
Same day shipping
In-house techniscal support
45 days worry-free returns

Do you have a question about this product?

Our employee is happy to help you find the right product

Product description

10 cm (4") high-end full-range loudspeaker with excellent balanced response characteristics and slightly increasing high-range for a pleasant sound even outside of 0-axis.

Highlights

Lightweight paper membrane
Impedance control ring
Aluminum die cast basket

Product details

Visaton B 100 4" High-End Full-Range Loudspeaker 6 Ohm

This woofer has excellent balanced response characteristics and slightly increasing high-range for a pleasant sound even outside of 0-axis. High efficiency with low distortion are just some of the qualities of this speaker.

Specifications

Article number: B 100
Woofer Series: High-End
Woofer Type: Full-Range
Nominal Diameter: 4"
Power Handling (RMS): 30 Watts
Power Handling (max): 60 Watts
Impedance (Z): 6 ohms
Sensitivity: 88 dB (1 W/1 m)
Frequency Response: 75 - 20,000 Hz
Voice Coil Diameter: 26 mm
DC Resistance (Re): 5.8 ohms
Voice Coil Inductance (Le): 0.36 mH
Resonant Frequency (Fs): 75 Hz
Mechanical Q (Qms): 10.13
Electromagnetic Q (Qes): 0.54
Total Q (Qts): 0.52
Diaphragm Mass Inc. Airload (Mms): 3.2g
Surface Area of Cone (Sd): 54.1 cm2
BL Product (BL): 4.1 Tm
Maximum Linear Excursion (Xmax): 1.6 mm
Cone / Diaphragm Material: Treated Paper
Surround Material: Rubber
Basket / Frame Material: Cast Aluminum
Overall Outside Diameter: 121.5 mm
Overall Depth: 57 mm
Baffle Cutout Diameter: 101 mm
Bolt Circle Diameter: 111 mm
# Mounting Holes: 4
Mounting Hole Diameter: 4.2 mm

Data sheet

Reviews

2 reviews

5 from 5Based on 2 reviews

Review this product

5 of 5

Prima solide speaker. Zit in parabolische hoorn en er komt gezien het formaat een zeer stevig geluid uit. Moet alleen nog met de demping aan de slag. Conclusie: AANRADER !!!!

By Paul G. on 4 November 2020

4 of 5

i have build it in a 3 liter cabinet made of azobe wood with bass reflex tube. the bass is excellent and there is a clear sound for the high frequenties. it is a better soundspectrum as the W4-1320.

By maurice v. on 21 February 2020
