      Tang Band W3-1876S 3" Mini Subwoofer

      € 41,28€ 49,95 10+ In stock
      • -5% Order 4 for only € 47,45 per piece

      Buy now, pay later

      • 24h express shipping available
      • Same day shipping
      • In-house techniscal support
      • 45 days worry-free returns
      Request quotation
      Do you have a question about this product?

      Do you have a question about this product?

      Our employee is happy to help you find the right product

      Product description

      A true long throw subwoofer, the diminutive Tang Band W3-1876S 3" driver provides a solid bass kick to the smallest possible speaker systems.



      Highlights
      • Great performance within a 3 inch small subwoofer design chassis
      • Patented structure design
      • New material applied with injection assembly process
      • Neodymium magnet motor with a long throw of Xmax and a 20 mm of voicecoil



      Product details

      Tang Band W3-1876S 3" Mini Subwoofer

      The Tang Band W3-1876S 3" subwoofer driver offers huge 5 mm Xmax capability and great sound quality in a tiny chassis. A compact yet powerful neodymium magnet system drives the 20 mm voice coil and patented injected polypropylene cone with Santoprene surround to impressively high bass output. The W3-1876S is suited for use in micro-sized home theater and multimedia audio systems.

      Show more

      Specifications

      Article number
      W3-1876S
      Woofer Type
      Subwoofer
      Nominal Diameter
      3"
      Power Handling (RMS)
      15 watts
      Power Handling (max)
      30 watts
      Impedance (Z)
      4 ohms
      Sensitivity
      76 dB 1W/1m
      Frequency Response
      55 - 2000 Hz
      Voice Coil Diameter
      0.8"
      DC Resistance (Re)
      3.6 ohms
      Voice Coil Inductance (Le)
      0.19 mH
      Resonant Frequency (Fs)
      55 Hz
      Mechanical Q (Qms)
      3.17
      Electromagnetic Q (Qes)
      0.5
      Total Q (Qts)
      0.43
      Diaphragm Mass Inc. Airload (Mms)
      9.98 g
      Mechanical Compliance of Suspension (Cms)
      0.74 mm/N
      Surface Area of Cone (Sd)
      27 cm²
      BL Product (BL)
      5.28 Tm
      Compliance Equivalent Volume (Vas)
      0.03 ft.³
      Maximum Linear Excursion (Xmax)
      5 mm
      Cone / Diaphragm Material
      Poly
      Surround Material
      Santoprene®
      Magnet Material
      Neodymium
      Overall Outside Diameter
      93.2 mm
      Overall Depth
      65.8 mm
      Baffle Cutout Diameter
      74.4 mm
      # Mounting Holes
      6
      Sealed Volume
      0.01 ft.³
      Sealed F3
      101 Hz
      Vented Volume
      0.03 ft.³
      Vented F3
      52 Hz

      Show more

      Reviews

      5 from 5Based on 4 reviews
      Review this product
      5 of 5
      Great quality, challenging to exploit but when u find tune it it is so fun when it finally sound great ! used in a micro desktop subwoofer.
      By Victor P. on 15 December 2020
      5 of 5
      super Produkt,gute Verarbeitung,Danke.
      By René B. on 16 May 2020
