The SD-9 adopts an architecture based on an ARM SoC and CPLD couple. The SoC takes care of the data decoding, while the CPLD takes care of the clock management of the audio signal. The clock signal is generated by two oscillators (22.5792MHz and 24.576MHz) in order to drastically reduce the jitter level and offer a very accurate sound reproduction.
The SMSL SD-9 is able to decode and play MQA (Master Quality Authenticated) files. These files allow to reach a sound quality as close as possible to the studio recording.
The SD-9 benefits from both wireless transmission via Bluetooth 4.0 and WiFi. It also supports DLNA and Apple AirPlay protocols for optimal compatibility with your other devices.
HiBy Link Compatible
The SD-9 will be able to connect very simply to the HiBy Link mobile application. This application will allow you, via a neat and intuitive graphical interface, to manage the playback of your music remotely.
A complete connectic
The SMSL network player is equipped with a particularly complete connectic to adapt to all the needs and all the audio systems. We can find in input USB-B (USB Audio), two USB-A connectors to connect storage devices, a slot for Micro SD card and an Ethernet RJ45 connector for a wired network connection. For its outputs, the SD-9 offers Toslink Optical, AES/EBU, Coaxial and I2S LVDS via HDMI.
Specifications: Product type: Streamer • Inputs: 2x USB-A (USB Host), 1x USB-B (USB Audio), 1x Micro SD slot, Bluetooth, WiFi, 1x Ethernet RJ45 • Outputs: 1x Optical Toslink, 1x Coaxial, 1x AES, Bluetooth, 1x USB, I2S LVDS via HDMI • Supported sampling rates: PCM up to 32bit 384kHz, DSD up to DSD256 • Max Micro SD card capacity: 256Go (not included) • Max storage drive capacity: 4TB • Max USB output current: 2A • DAC output function • Bluetooth version: 4.0 • Supported Bluetooth codec: aptX • HiBy Link compatibility • WiFi bandwidth: 2.4G/5G • Dimensions: 187.4 x 154.5 x 42mm • Operating consumption: 2W • Standby consumption 0.5W.
What’s in the Box?
- 1 x Remote control
- 1 x External antenna
- 1 x USB audio
- 1 x Power cable
