        Excel W26FX002 - E0046-08S 10" Nextel Coated Paper Cone Woofer

        Excel W26FX002 - E0046-08S 10" Nextel Coated Paper Cone Woofer

        €549,95

        SEAS Excel W26FX002 - E0046-08S 10" Nextel Coated Paper Cone Woofer

        0 reviews
        0 from 5
        0 reviews
        5 stars
        0%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: SEAS
        € 454,50€ 549,95 6 In stock
        • -5% Purchase 4 for only € 522,45 per piece

        Buy now, pay later

        • We ship to
        • Ordered now, shipped today
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        Product description

        Highlights

        • Long term power handling (RMS) is 100 Watts
        • Unique Nextel coating ensures smooth frequency response and low distortion
        • Reduced compression, increased long term power handling capacity and eliminated resonances in the cavity inside the voice coil former



        Product details

        Seas Excel W26FX002 - E0046-08S 10" Nextel Coated Paper Cone Woofer



        A paper cone with a unique Nextel coating ensures smooth frequency response and low distortion. 2” diameter high temperature voice coil with black anodized coil former for high power handling and reduced power compression.



        Heavy copper rings mounted above and below the T-shaped pole piece reduce non linear and modulation distortion and increase overload margin. A chrome plated brass phase plug reduces compression due to temperature variations in the voice coil, increases long term power handling capacity and eliminates resonances in the cavity inside the voice coil former.



        Extremely stiff and stable injection molded metal basket with Nextel paint keeps the critical components in perfect alignment. Large windows in the basket both above and below the spider reduce sound reflexion, air flow noise and cavity resonance to a minimum.

        Show more

        Specifications

        Article number
        W26FX002
        Woofer Series
        Excel Series
        Woofer Type
        Midwoofer
        Nominal Diameter
        10"
        Power Handling (RMS)
        100 Watts
        Power Handling (max)
        300 Watts
        Impedance (Z)
        8 ohms
        Sensitivity (SPL at 1m / 2.83V)
        89 dB
        Frequency Response
        30 to 1,000 Hz
        Voice Coil Diameter
        2"
        Magnet Weight
        45.8 oz.
        DC Resistance (Re)
        6.2 ohms
        Voice Coil Inductance (Le)
        0.81 mH
        Resonant Frequency (Fs)
        31 Hz
        Mechanical Q (Qms)
        2.55
        Electromagnetic Q (Qes)
        0.47
        Total Q (Qts)
        0.39
        Diaphragm Mass Inc. Airload (Mms)
        42.4g
        Mechanical Compliance of Suspension (Cms)
        0.6 mm/N
        Compliance Equivalent Volume (Vas)
        3.07 ft.³
        Maximum Linear Excursion (Xmax)
        7 mm
        Overall Outside Diameter
        10.59"
        Overall Depth
        4.54"
        Baffle Cutout Diameter
        9.14"
        Bolt Circle Diameter
        10.08"
        # Mounting Holes
        6

        Show more
