        Excel W22NX001 - E0077-08 Woofer

        SEAS Excel W22NX001 - E0077-08 Woofer

        €629,95

        2 In stock

        Add to cart

        SEAS Excel W22NX001 - E0077-08 Woofer

        0 reviews
        0 from 5
        0 reviews
        5 stars
        0%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: SEAS
        Show all Bass-mid woofer
        8" | 8 Ω
        Excel W22NX001 - E0077-08 Woofer
        Excel W22NX001 - E0077-08 Woofer
        Excel W22NX001 - E0077-08 Woofer
        Excel W22NX001 - E0077-08 Woofer
        Excel W22NX001 - E0077-08 Woofer
        Excel W22NX001 - E0077-08 Woofer
        Excel W22NX001 - E0077-08 Woofer
        Excel W22NX001 - E0077-08 Woofer
        Excel W22NX001 - E0077-08 Woofer
        Excel W22NX001 - E0077-08 Woofer
        Excel W22NX001 - E0077-08 Woofer
        Excel W22NX001 - E0077-08 Woofer
        € 520,62€ 629,95 2 In stock
        • -5% Purchase 4 for only € 598,45 per piece
        +-
        Add to cart

        Buy now, pay later

        • We ship to
        • Same day shipping
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        Excel W22NX001 - E0077-08 Woofer
        Excel W22NX001 - E0077-08 Woofer
        Excel W22NX001 - E0077-08 Woofer
        Excel W22NX001 - E0077-08 Woofer
        Excel W22NX001 - E0077-08 Woofer
        Excel W22NX001 - E0077-08 Woofer
        Excel W22NX001 - E0077-08 Woofer
        Excel W22NX001 - E0077-08 Woofer
        Excel W22NX001 - E0077-08 Woofer
        Excel W22NX001 - E0077-08 Woofer
        Excel W22NX001 - E0077-08 Woofer
        Excel W22NX001 - E0077-08 Woofer

        Pros and cons

        According to our specialists
        • Titanium voice coil former and an FEA-optimized magnet system.
        • Flux density 1.3 T, Winding material is Copper and Surround material is Rubbe

        Product description SEAS W22NX001 - E0077-08 Woofer

        The SEAS W22NX001 - E0077-08 is a high-performance 8-inch woofer that features a precision-cast, machined, and graphene-treated magnesium cone, a titanium voice coil former, and an FEA-optimized magnet system. This combination of components results in a woofer that is capable of producing accurate and detailed sound reproduction with excellent bass response.



        Highlights

        • Precision-cast, machined, and graphene-treated magnesium cone
        • Titanium voice coil former
        • FEA-optimized magnet system
        • Extremely stiff and stable injection-molded metal basket



        Product details

        SEAS Excel W22NX001 - E0077-08 Woofer



        The SEAS W22NX001 - E0077-08 includes a precision-cast, machined, and graphene-treated magnesium cone, its titanium voice coil former, and its FEA-optimized magnet system. The magnesium cone is extremely stiff and lightweight, which helps to reduce distortion and improve sound quality. The graphene treatment also helps to improve the cone's damping properties, which further reduces distortion. The titanium voice coil former is very strong and lightweight, which helps to improve the woofer's power handling and transient response. The titanium material also has excellent heat dissipation properties, which helps to prevent the voice coil from overheating. The FEA-optimized magnet system is designed to provide excellent linearity, high power handling, and low distortion. The precise fit of the copper parts in the magnet system helps to reduce air gaps and improve efficiency.

        Show more

        Specifications

        Article number
        W22NX001
        EAN
        8785256848744
        Woofer Series
        Excel Graphene
        Nominal Diameter
        8 " | 221 mm
        Power Handling (RMS)
        200 W
        Power Handling (max)
        500 W
        Continuous Program Power
        500 Watt
        Impedance (Z)
        8 Ω
        Sensitivity (SPL at 1m / 2.83V)
        87.3 dB
        Frequency Response
        20 - 2000 Hz
        Voice Coil Diameter
        39 mm
        Magnet Weight
        0.9 kg
        DC Resistance (Re)
        6.3 Ω
        Voice Coil Inductance (Le)
        0.26 mH
        Resonant Frequency (Fs)
        25 Hz
        Mechanical Q (Qms)
        4.18
        Electromagnetic Q (Qes)
        0.44
        Total Q (Qts)
        0.39
        Diaphragm Mass Inc. Airload (Mms)
        31.1 g
        Moving Mass Of Diaphragm (Mmd)
        31.1 g
        Mechanical Compliance of Suspension (Cms)
        1.35 mm/N
        Surface Area of Cone (Sd)
        220 cm²
        BL Product (BL)
        8.3 N/A
        Compliance Equivalent Volume (Vas)
        93 L
        Maximum Linear Excursion (Xmax)
        7 mm
        Driver's Mechanical Losses (Rms)
        1.15 Ns/m
        Cone / Diaphragm Material
        Graphene treated magnesium
        Voice Coil Wire Material
        Copper
        Voice Coil Former
        Titanium
        Basket / Frame Material
        Injection moulded metal
        Overall Outside Diameter
        221 mm
        Overall Depth
        93 mm
        Baffle Cutout Diameter
        186.4 mm
        Bolt Circle Diameter
        209.5 mm
        # Mounting Holes
        6
        Mounting Hole Diameter
        5.0 mm

        Show more
