- Article number
- MCA12RC
- Woofer Series
- Prestige Series
- Nominal Diameter
- 4.5"
- Power Handling (RMS)
- 110 Watts
- Power Handling (max)
- 400 Watts
- Impedance (Z)
- 8 ohms
- Sensitivity
- 86 dB 2.83V/1m
- Frequency Response
- 400 to 5,000 Hz
- Voice Coil Diameter
- 1.02"
- Magnet Weight
- 8.81 oz.
- DC Resistance (Re)
- 6.3 ohms
- Voice Coil Inductance (Le)
- 0.31 mH
- Resonant Frequency (Fs)
- 68 Hz
- Mechanical Q (Qms)
- 2.42
- Electromagnetic Q (Qes)
- 0.74
- Total Q (Qts)
- 0.56
- Diaphragm Mass Inc. Airload (Mms)
- 4.58g
- Mechanical Compliance of Suspension (Cms)
- 1.2 mm/N
- Compliance Equivalent Volume (Vas)
- 0.17 ft.³
- Maximum Linear Excursion (Xmax)
- 0.9 mm
- Overall Outside Diameter
- 4.74"
- Overall Depth
- 2.38"
- Baffle Cutout Diameter
- 3.77"
- Bolt Circle Diameter
- 4.36"
- # Mounting Holes
- 6
- Mounting Hole Diameter
- 0.2"
