        Orbit FL4RCN/F - OR003-04 Micro Driver

        SEAS Orbit FL4RCN/F - OR003-04 Micro Driver

        €15,95

        7 In stock10+ expected on 24-07-2026

        Add to cart

        SEAS Orbit FL4RCN/F - OR003-04 Micro Driver

        0 reviews
        0 from 5
        0 reviews
        5 stars
        0%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: SEAS
        Show all Woofers
        2" | 4 Ω
        Orbit FL4RCN/F - OR003-04 Micro Driver
        Orbit FL4RCN/F - OR003-04 Micro Driver
        Orbit FL4RCN/F - OR003-04 Micro Driver
        Orbit FL4RCN/F - OR003-04 Micro Driver
        Orbit FL4RCN/F - OR003-04 Micro Driver
        Orbit FL4RCN/F - OR003-04 Micro Driver
        Orbit FL4RCN/F - OR003-04 Micro Driver
        Orbit FL4RCN/F - OR003-04 Micro Driver
        Orbit FL4RCN/F - OR003-04 Micro Driver
        Orbit FL4RCN/F - OR003-04 Micro Driver
        Orbit FL4RCN/F - OR003-04 Micro Driver
        Orbit FL4RCN/F - OR003-04 Micro Driver
        € 13,18€ 15,95 7 In stock10+ expected on 24-07-2026
        • -5% Purchase 4 for only € 15,15 per piece
        +-
        Add to cart

        Buy now, pay later

        • We ship to
        • Same day shipping
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        Orbit FL4RCN/F - OR003-04 Micro Driver
        Orbit FL4RCN/F - OR003-04 Micro Driver
        Orbit FL4RCN/F - OR003-04 Micro Driver
        Orbit FL4RCN/F - OR003-04 Micro Driver
        Orbit FL4RCN/F - OR003-04 Micro Driver
        Orbit FL4RCN/F - OR003-04 Micro Driver
        Orbit FL4RCN/F - OR003-04 Micro Driver
        Orbit FL4RCN/F - OR003-04 Micro Driver
        Orbit FL4RCN/F - OR003-04 Micro Driver
        Orbit FL4RCN/F - OR003-04 Micro Driver
        Orbit FL4RCN/F - OR003-04 Micro Driver
        Orbit FL4RCN/F - OR003-04 Micro Driver

        Product description SEAS Orbit FL4RCN/F - OR003-04 Micro Woofer

        The FL4RCN/F is a full range driver offering an extra ordinary performance and sound clarity. An aluminum cone with excellent internal damping, together with perfectly matched surround, gives a smooth and extended frequency response.



        Highlights

        • Stiff and stable plastic chassis keeps the critical components in perfect alignment
        • copper cap to ensure exceptional linearity in the force factor and coil inductance
        • for any application where limited space



        Product details

        SEAS Orbit FL4RCN/F - OR003-04 Micro Driver



        The FL4RCN/F is a full range driver offering an extra ordinary performance and sound clarity. An aluminum cone with excellent internal damping, together with perfectly matched surround, gives a smooth and extended frequency response. The fabric spider reflects very little acoustic energy to the cone and offers outstanding stiffness linearity. A stiff and stable plastic chassis keeps the critical components in perfect alignment. The pole piece performs a copper cap to ensure exceptional linearity in the force factor and coil inductance. Small size comined with an excellent performance makes this driver the perfect choice for any application where limited space is a critical parameter.

        Show more

        Specifications

        Article number
        FL4RCN/F
        EAN
        8785256845989
        Woofer Series
        Orbit
        Woofer Type
        Full Range
        Nominal Diameter
        1.5 " | 40 mm
        Power Handling (RMS)
        3 W
        Power Handling (max)
        4 W
        Impedance (Z)
        4 Ω
        Sensitivity (SPL at 1m / 2.83V)
        84.1 dB
        Frequency Response
        200 - 20000 Hz
        Voice Coil Diameter
        26 mm
        Magnet Weight
        0.021 kg
        DC Resistance (Re)
        3.64 Ω
        Voice Coil Inductance (Le)
        0.09 mH
        Resonant Frequency (Fs)
        140 Hz
        Mechanical Q (Qms)
        1.56
        Electromagnetic Q (Qes)
        0.48
        Total Q (Qts)
        0.37
        Diaphragm Mass Inc. Airload (Mms)
        1.21 g
        Mechanical Compliance of Suspension (Cms)
        1.07 mm/N
        Surface Area of Cone (Sd)
        9.08 cm²
        BL Product (BL)
        2.8 N/A
        Compliance Equivalent Volume (Vas)
        0.13 L
        Maximum Linear Excursion (Xmax)
        2.7 mm
        Driver's Mechanical Losses (Rms)
        0.68 Ns/m
        Cone / Diaphragm Material
        Aluminum
        Surround Material
        Rubber
        Basket / Frame Material
        Plastic
        Magnet Material
        Neodymium
        Overall Outside Diameter
        40 mm
        Overall Depth
        15 mm
        Baffle Cutout Diameter
        36 mm
        # Mounting Holes
        4

        Show more
