      Scan-Speak Classic D2904/980000 1" Tweeter Aluminum Dome

      € 177,64€ 214,95 2 In stock: delivery time 1-4 business days
      Bulk discount Enjoy these awesome discount deals
      • -5% Order 4 for only €204,20 per piece
      • 24h express shipping available
      • Low international shipping rates
      • Same day shipping
      • In-house technical support
      Do you have a question about this product?

      Do you have a question about this product?

      Our employee is happy to help you find the right product

      Product description

      Highlights

      • 1" Aluminium Dome Diaphragm
      • Patented Symmetrical Drive (SD) motor
      • Wave Guide
      • Low Resonance Rear Chamber
      • Black Painted Alu Face Plate



      Product details

      ScanSpeak Classic D2904/980000 1" Tweeter Aluminum Dome



      The Scan-speak D2904/9800 is a high-end 1" aluminum dome tweeter. The magnet system uses the Symmetric Drive technology that almost eliminates electrical phase shift. The specially designed chamber reduces air noise and compression. The geometry of the dome causes the "break-up" to appear beyond the audible range. A specially designed diffusor is used to equalize the response in the upper octave. The tweeter has a very clear and open sound.



      Specifications: BL Product (BL): 2.8 Tm • Mechanical Compliance of Suspension (Cms): 0.20 mm/N • Diaphragm Mass Inc. Airload (Mms): 0. 6 g • Maximum Linear Excursion (Xmax): 0.1 mm • Surface Area of Cone (Sd): 8.5 cm2

      Specifications

      Article number
      D2904/980000
      Tweeter Type
      Dome
      Tweeter Series
      Classic Series
      Cone / Dome Diameter
      25 mm | 1"
      Power Handling (RMS)
      160 Watts
      Power Handling (max)
      430 Watts
      Impedance (Z)
      4 Ω
      Sensitivity
      88 dB 2.83V/1m
      Frequency Response
      1,000 to 18,000Hz
      Resonant Frequency (Fs)
      500 Hz
      DC Resistance (Re)
      3.5 ohms
      Voice Coil Inductance (Le)
      0.01 mH
      Mechanical Q (Qms)
      3.09
      Electromagnetic Q (Qes)
      0.84
      Total Q (Qts)
      0.66

      Show more

      Reviews

      5 from 5Based on 1 reviews
      Review this product
      5 of 5
      Top geluid. De kat had de vorige tweeters gemold, die waren van hetzelfde type allen uit 2006, dus inmiddels 15 jaar oud. Blijft een van de beste tweeters die je kunt kopen. geluid is helder, zonder schel te zijn. Heel veel detail.
      By Michiel K. on 10 February 2021
