        NERO-5CCN125D Mid-range Woofer

        SB Audience NERO-5CCN125D Mid-range Woofer

        €169,95

        Out of stock

        Add to cart

        SB Audience NERO-5CCN125D Mid-range Woofer

        0 reviews
        0 from 5
        0 reviews
        5 stars
        0%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: SB Audience
        Show all New products
        5" | 8 Ω
        NERO-5CCN125D Mid-range Woofer
        NERO-5CCN125D Mid-range Woofer
        NERO-5CCN125D Mid-range Woofer
        NERO-5CCN125D Mid-range Woofer
        NERO-5CCN125D Mid-range Woofer
        NERO-5CCN125D Mid-range Woofer
        NERO-5CCN125D Mid-range Woofer
        NERO-5CCN125D Mid-range Woofer
        NERO-5CCN125D Mid-range Woofer
        NERO-5CCN125D Mid-range Woofer
        € 140,45€ 169,95 Out of stock
        • -5% Purchase 4 for only € 161,45 per piece
        +-
        Add to cart

        Buy now, pay later

        • We ship to
        • Back in stock soon
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        NERO-5CCN125D Mid-range Woofer
        NERO-5CCN125D Mid-range Woofer
        NERO-5CCN125D Mid-range Woofer
        NERO-5CCN125D Mid-range Woofer
        NERO-5CCN125D Mid-range Woofer
        NERO-5CCN125D Mid-range Woofer
        NERO-5CCN125D Mid-range Woofer
        NERO-5CCN125D Mid-range Woofer
        NERO-5CCN125D Mid-range Woofer
        NERO-5CCN125D Mid-range Woofer

        Pros and cons

        According to our specialists
        • Removable cast aluminum rear chamber
        • Suitable for high compression midrange applications

        Product description SB Audience NERO-5CCN125D Mid-range Woofer

        High-efficiency 5-inch midrange driver built for demanding audio environments. The NERO-5CCN125D delivers outstanding clarity and low distortion, making it ideal for high-compression midrange applications in both professional and high-end DIY setups.



        Highlights of the NERO NERO-5CCN125D

        • 99 dB sensitivity with wide frequency response (355 – 20,000 Hz)
        • Robust 125W AES power handling, 250W max power
        • Neodymium magnet and copper sleeve for reduced distortion
        • Removable rear chamber with die-cast aluminum basket



        Product details NERO NERO-5CCN125D

        NERO NERO-5CCN125D 5” Midrange Loudspeaker



        The NERO-5CCN125D is a 5-inch high-efficiency midrange driver engineered for precision and low distortion in professional sound systems and advanced DIY loudspeaker projects. With a powerful neodymium magnet and copper sleeve demodulation ring, it maintains low inductance and minimizes intermodulation distortion. Its pure carbon fiber cone and inverted low-mass surround deliver exceptional midrange clarity. This driver handles 125W AES and up to 250W peak power while achieving up to 99 dB sensitivity (with chamber) at 2.83V/1m.



        The robust cast aluminum chassis supports a removable rear chamber, enhancing its flexibility for varied cabinet designs. It incorporates a 38.5 mm voice coil wound with copper-clad aluminum on a fiberglass former, allowing it to perform reliably under high thermal loads. Key technical parameters include a resonant frequency (Fs) of 122 Hz (without chamber), Xmax of 3.2 mm, and a net air volume displacement of 0.59 liters. Its optimized Thiele-Small parameters make it suitable for high-efficiency midrange horn or sealed applications where space and sound pressure level are critical.

        Show more

        Specifications

        Article number
        NERO-5CCN125D
        EAN
        9502219616931
        Woofer Type
        Mid Range Woofer
        Nominal Diameter
        5”
        Power Handling (RMS)
        125 Watts
        Power Handling (max)
        250 Watts
        Impedance (Z)
        8 Ω
        Sensitivity (SPL at 1m / 2.83V)
        Chamber 99 dB. no chamber 97 dB
        Frequency Response
        355 - 20.000 Hz
        Voice Coil Diameter
        38.5 mm
        DC Resistance (Re)
        5.4 Ω
        Voice Coil Inductance (Le)
        Chamber 0.03 mH, No chamber 0.07 mH
        Resonant Frequency (Fs)
        Chamber 360 Hz, No chamber 122 Hz
        Mechanical Q (Qms)
        Chamber 16.6, No chamber 9.61
        Electromagnetic Q (Qes)
        Chamber 0.76, No chamber 0.28
        Total Q (Qts)
        Chamber 0.73, No chamber 0.28
        Diaphragm Mass Inc. Airload (Mms)
        7.9 g
        Mechanical Compliance of Suspension (Cms)
        Chamber 0.03 mm/N, No chamber 0.22 mm/N
        Surface Area of Cone (Sd)
        93.3 cm²
        BL Product (BL)
        10.6 Tm
        Compliance Equivalent Volume (Vas)
        Chamber 0.3 Liters, No chamber 2.70 Liters
        Maximum Linear Excursion (Xmax)
        3.2 mm
        Voice Coil Former
        Till
        Magnet Material
        Neodymium
        Overall Outside Diameter
        159 mm
        Baffle Cutout Diameter
        Chamber 125 mm. No chamber 120.3 mm
        Bolt Circle Diameter
        142 mm
        # Mounting Holes
        4
        Mounting Hole Diameter
        4 mm
