        SB23NBACS45-8 8" Black Aluminum Cone Woofer

        SB Acoustics SB23NBACS45-8 8" Black Aluminum Cone Woofer

        €134,95

        6 In stock

        Add to cart

        SB Acoustics SB23NBACS45-8 8" Black Aluminum Cone Woofer

        0 reviews
        0 from 5
        0 reviews
        5 stars
        0%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: SB Acoustics
        8" | 8 Ω
        SB23NBACS45-8 8" Black Aluminum Cone Woofer
        SB23NBACS45-8 8" Black Aluminum Cone Woofer
        SB23NBACS45-8 8" Black Aluminum Cone Woofer
        SB23NBACS45-8 8" Black Aluminum Cone Woofer
        SB23NBACS45-8 8" Black Aluminum Cone Woofer
        SB23NBACS45-8 8" Black Aluminum Cone Woofer
        SB23NBACS45-8 8" Black Aluminum Cone Woofer
        SB23NBACS45-8 8" Black Aluminum Cone Woofer
        SB23NBACS45-8 8" Black Aluminum Cone Woofer
        SB23NBACS45-8 8" Black Aluminum Cone Woofer
        SB23NBACS45-8 8" Black Aluminum Cone Woofer
        SB23NBACS45-8 8" Black Aluminum Cone Woofer
        € 111,53€ 134,95 6 In stock
        • -5% Purchase 4 for only € 128,20 per piece
        € 134,95
        +-
        Add to cart
        🔒 Secure payment
        MastercardVisaBank TransferCarte BancaireApple PayGoogle Paypaypal

        Buy now, pay later

        • We ship to
        • Same day shipping
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        SB23NBACS45-8 8" Black Aluminum Cone Woofer
        SB23NBACS45-8 8" Black Aluminum Cone Woofer
        SB23NBACS45-8 8" Black Aluminum Cone Woofer
        SB23NBACS45-8 8" Black Aluminum Cone Woofer
        SB23NBACS45-8 8" Black Aluminum Cone Woofer
        SB23NBACS45-8 8" Black Aluminum Cone Woofer
        SB23NBACS45-8 8" Black Aluminum Cone Woofer
        SB23NBACS45-8 8" Black Aluminum Cone Woofer
        SB23NBACS45-8 8" Black Aluminum Cone Woofer
        SB23NBACS45-8 8" Black Aluminum Cone Woofer
        SB23NBACS45-8 8" Black Aluminum Cone Woofer
        SB23NBACS45-8 8" Black Aluminum Cone Woofer

        Product description SB Acoustics SB23NBACS45-8 Bass-midwoofer

        Highlights

        • Soft low damping rubber surround for improved transient response
        • Geometrically reinforced aluminum cone for improved break-up control
        • Shorting ring in motor system for reduced distortion
        • Vented pole piece for reduced compression
        • Vented cast aluminum chassis for optimum strength and low compression
        • Shallow design
        • Non-conducting fiber glass voice coil former for minimum damping
        • CCAW voice coil for reduced moving mass
        • Long life silver lead wires



        Product details

        SB Acoustics SB23NBACS45-8 8" Black Aluminum Cone Woofer



        The SB Acoustics SB23NBACS45-8 features a soft low damping rubber surround for improved transient response and a geometrically reinforced aluminum cone for improved break-up control. Shorting ring in motor system for reduced distortion and vented pole piece for reduced compression. Vented cast aluminum chassis for optimum strength and low compression and non-conducting fiber glass voice coil former for minimum damping. CCAW voice coil for reduced moving mass. Long life silver lead wires.

        Show more

        Specifications

        Article number
        SB23NBACS45-8
        EAN
        0696277269501
        Woofer Series
        SB Acoustics NAC Aluminum series
        Woofer Type
        8
        Power Handling (RMS)
        60 Watt
        Impedance (Z)
        8 Ω
        Sensitivity (SPL at 1m / 2.83V)
        87.5 dB
        Frequency Response
        50 - 18.000 Hz
        Voice Coil Diameter
        46 mm
        DC Resistance (Re)
        5.7 Ω
        Voice Coil Inductance (Le)
        0.37 mH
        Resonant Frequency (Fs)
        25 Hz
        Mechanical Q (Qms)
        5.54
        Electromagnetic Q (Qes)
        0.43
        Total Q (Qts)
        0.4
        Diaphragm Mass Inc. Airload (Mms)
        31.2 g
        Mechanical Compliance of Suspension (Cms)
        1.43 mm/N
        Surface Area of Cone (Sd)
        216 cm²
        BL Product (BL)
        7.9 Tm
        Compliance Equivalent Volume (Vas)
        93.2 L
        Maximum Linear Excursion (Xmax)
        6.5 mm
        Cone / Diaphragm Material
        Paper
        Voice Coil Wire Material
        CCAW
        Voice Coil Former
        Kapton
        Basket / Frame Material
        Stamped Steel
        Magnet Material
        Ferrite
        Overall Outside Diameter
        209 mm
        Baffle Cutout Diameter
        181 mm
