      SB Acoustics SB23NACS45-8 8" Aluminum Cone Woofer

      € 90,87€ 109,95 2 In stock: delivery time 1-4 business days
      Bulk discount Enjoy these awesome discount deals
      • -5% Order 4 for only €104,45 per piece
      • 24h express shipping available
      • Low international shipping rates
      • Same day shipping
      • In-house technical support
      Do you have a question about this product?

      Do you have a question about this product?

      Our employee is happy to help you find the right product

      Product description

      Highlights

      • Soft low damping rubber surround for improved transient response
      • Geometrically reinforced aluminum cone for improved break-up control
      • Shorting ring in motor system for reduced distortion
      • Vented pole piece for reduced compression
      • Vented cast aluminum chassis for optimum strength and low compression
      • Shallow design
      • Non-conducting fiber glass voice coil former for minimum damping
      • CCAW voice coil for reduced moving mass
      • Long life silver lead wires



      Product details

      SB Acoustics SB23NACS45-8 8" Aluminum Cone Woofer



      The SB Acoustics SB23NACS45-8 features a soft low damping rubber surround for improved transient response and a geometrically reinforced aluminum cone for improved break-up control. Shorting ring in motor system for reduced distortion and vented pole piece for reduced compression. Vented cast aluminum chassis for optimum strength and low compression and non-conducting fiber glass voice coil former for minimum damping. CCAW voice coil for reduced moving mass. Long life silver lead wires.

      Specifications

      Article number
      SB23NACS45-8
      Woofer Series
      NAC Series
      Woofer Type
      Full-range
      Nominal Diameter
      8"
      Power Handling (RMS)
      60 Watts
      Impedance (Z)
      8 ohms
      Sensitivity
      87.5 dB 2.83V/1m
      Voice Coil Diameter
      1.79"
      DC Resistance (Re)
      5.6 ohms
      Voice Coil Inductance (Le)
      0.60 mH
      Resonant Frequency (Fs)
      25 Hz
      Mechanical Q (Qms)
      5.6
      Electromagnetic Q (Qes)
      0.4
      Total Q (Qts)
      0.37
      Diaphragm Mass Inc. Airload (Mms)
      28.5 g
      Mechanical Compliance of Suspension (Cms)
      1.42 mm/N
      Surface Area of Cone (Sd)
      216 cm2
      BL Product (BL)
      7.9 Tm
      Compliance Equivalent Volume (Vas)
      3.31 ft.³
      Maximum Linear Excursion (Xmax)
      13 mm

      Show more

      Reviews

      5 from 5Based on 1 reviews
      Review this product
      5 of 5
