        SB17NAC35-4 6'' Aluminum Cone Woofer

        SB17NAC35-4 6'' Aluminum Cone Woofer

        €82,45

        SB Acoustics SB17NAC35-4 6'' Aluminum Cone Woofer

        1 reviews
        5 from 5
        1 reviews
        5 stars
        100%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        € 68,14€ 82,45 2 In stock
        • -5% Purchase 4 for only € 78,33 per piece

        Buy now, pay later

        • We ship to
        • Ordered now, shipped tomorrow
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        Product description

        Highlights

        • Vented cast aluminum chassis for optimum strength and low compression
        • Geometrically reinforced aluminum cone for optimum piston operation and reduced break-up
        • Soft low damping rubber surround for improved transient response
        • Non-conducting fiber glass voice coil former for minimum damping
        • Extended copper sleeve on pole piece for low inductance and low distortion
        • CCAW voice coil for reduced moving mass
        • Long life silver lead wires
        • Vented pole piece for reduced compression



        Product details

        SB Acoustics SB17NAC35-4 6'' Aluminum Cone Woofer



        The SB Acoustics SB17NAC35-4 features a vented cast aluminum chassis for optimum strength and low compression and a geometrically reinforced aluminum cone for optimum piston operation and reduced break-up. Soft low damping rubber surround for improved transient response. Non-conducting fiber glass voice coil former for minimum damping and extended copper sleeve on pole piece for low inductance and low distortion. CCAW voice coil for reduced moving mass. Long life silver lead wires. Vented pole piece for reduced compression.

        Show more

        Specifications

        Article number
        SB17NAC35-4
        Woofer Series
        NAC Series
        Woofer Type
        Midwoofer
        Nominal Diameter
        6"
        Power Handling (RMS)
        60 Watts
        Impedance (Z)
        4 ohms
        Sensitivity (SPL at 1m / 2.83V)
        90 dB
        Voice Coil Diameter
        1.39"
        DC Resistance (Re)
        3.1 ohms
        Voice Coil Inductance (Le)
        0.13 mH
        Resonant Frequency (Fs)
        32 Hz
        Mechanical Q (Qms)
        5.95
        Electromagnetic Q (Qes)
        0.34
        Total Q (Qts)
        0.32
        Diaphragm Mass Inc. Airload (Mms)
        14.8 g
        Mechanical Compliance of Suspension (Cms)
        1.67 mm/N
        Surface Area of Cone (Sd)
        118 cm2
        BL Product (BL)
        5.2 Tm
        Compliance Equivalent Volume (Vas)
        1.16 ft.³
        Maximum Linear Excursion (Xmax)
        5.5 mm

        Show more

        5 of 5
        Fantastic detailed driver, I was literally blown away by the amount of bass it can produce in a 17 litre vented box
        By Jaikub on 23 March 2021
