        SB17CAC35-8 6" Ceramic Woofer

        SB Acoustics SB17CAC35-8 6" Ceramic Woofer

        €104,95

        8 In stock

        Add to cart

        SB Acoustics SB17CAC35-8 6" Ceramic Woofer

        3 reviews
        5 from 5
        3 reviews
        5 stars
        100%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: SB Acoustics
        6" | 8 Ω
        SB17CAC35-8 6" Ceramic Woofer
        SB17CAC35-8 6" Ceramic Woofer
        SB17CAC35-8 6" Ceramic Woofer
        SB17CAC35-8 6" Ceramic Woofer
        SB17CAC35-8 6" Ceramic Woofer
        SB17CAC35-8 6" Ceramic Woofer
        SB17CAC35-8 6" Ceramic Woofer
        SB17CAC35-8 6" Ceramic Woofer
        SB17CAC35-8 6" Ceramic Woofer
        SB17CAC35-8 6" Ceramic Woofer
        SB17CAC35-8 6" Ceramic Woofer
        SB17CAC35-8 6" Ceramic Woofer
        € 86,74€ 104,95 8 In stock
        • -5% Purchase 4 for only € 99,70 per piece
        € 104,95
        +-
        Add to cart
        🔒 Secure payment
        MastercardVisaBank TransferCarte BancaireApple PayGoogle Paypaypal

        Buy now, pay later

        • We ship to
        • Ordered now, shipped on Monday
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        SB17CAC35-8 6" Ceramic Woofer
        SB17CAC35-8 6" Ceramic Woofer
        SB17CAC35-8 6" Ceramic Woofer
        SB17CAC35-8 6" Ceramic Woofer
        SB17CAC35-8 6" Ceramic Woofer
        SB17CAC35-8 6" Ceramic Woofer
        SB17CAC35-8 6" Ceramic Woofer
        SB17CAC35-8 6" Ceramic Woofer
        SB17CAC35-8 6" Ceramic Woofer
        SB17CAC35-8 6" Ceramic Woofer
        SB17CAC35-8 6" Ceramic Woofer
        SB17CAC35-8 6" Ceramic Woofer

        Product description SB Acoustics SB17CAC35-8 Bass-midwoofer

        Highlights

        • Vented cast aluminum chassis for optimum strength and low compression
        • Geometrically reinforced ceramic cone for optimum piston operation and reduced break-up
        • Soft low damping rubber surround for improved transient response
        • Non-conducting fiber glass voice coil former for minimum damping
        • Extended copper sleeve on pole piece for low inductance and low distortion
        • CCAW voice coil for reduced moving mass
        • Long life silver lead wires
        • Vented pole piece for reduced compression



        Product details

        SB Acoustics SB17CAC35-8 6" Ceramic Woofer



        SB Ceramic cones consist of an aluminum/ceramic dual layer cone. Ceramic provides a very hard and robust surface with improved sonic properties and cosmetic appearance.



        Other than that, ceramic cones offer smoothness and harmonic richness unavailable from conventional paper cone material. Ceramic materials also offer significantly higher stiffness numbers and slightly better internal losses than typical metals such as titanium or aluminum. Compared to polymers, paper, and other soft materials, ceramics provide: significantly higher stiffness to weight ratio, more consistent performance over a wide range of temperature and humidity as well as superior immunity to UV light and sunlight, to water and salt water and to combustibility.

        Show more

        Specifications

        Article number
        SB17CAC35-8
        EAN
        0696277269372
        Woofer Series
        SB Acoustics CAC Ceramic series
        Woofer Type
        Midwoofer
        Nominal Diameter
        6"
        Power Handling (RMS)
        60 Watt
        Impedance (Z)
        8 Ω
        Sensitivity (SPL at 1m / 2.83V)
        86.5 dB
        Frequency Response
        75 - 5500 Hz
        Voice Coil Diameter
        36 mm
        DC Resistance (Re)
        5.7 Ω
        Voice Coil Inductance (Le)
        0.15 mH
        Resonant Frequency (Fs)
        28 Hz
        Mechanical Q (Qms)
        4.46
        Electromagnetic Q (Qes)
        0.4
        Total Q (Qts)
        0.36
        Diaphragm Mass Inc. Airload (Mms)
        15.4 g
        Mechanical Compliance of Suspension (Cms)
        2.13 mm/N
        Surface Area of Cone (Sd)
        118 cm²
        BL Product (BL)
        6.2 Tm
        Compliance Equivalent Volume (Vas)
        41.9 L
        Maximum Linear Excursion (Xmax)
        5.5 mm
        Cone / Diaphragm Material
        Paper
        Voice Coil Wire Material
        CCAW
        Voice Coil Former
        Kapton
        Basket / Frame Material
        Stamped Steel
        Magnet Material
        Ferrite
        Overall Outside Diameter
        257 mm
        Baffle Cutout Diameter
        235 mm

        Show more

        Reviews

        3 reviews
        Review this product
        5 of 5
        With the right crossower heavenly sound. Deep and precise bass, juicy mids full of details. Six stars out of five. I can only highly recommend.
        By Jozef on 23 June 2022
        5 of 5
        Used in CB with 33ltr. capacitor 800 myF.
        (Closed with a high pass) = 30Hz!
        By lufton on 31 August 2020
