        SB15NBAC30-8 5" Black Aluminum Cone Mid-bass

        SB15NBAC30-8 5" Black Aluminum Cone Mid-bass

        €82,95

        SB Acoustics SB15NBAC30-8 5" Black Aluminum Cone Mid-bass

        0 reviews
        0 from 5
        0 reviews
        5 stars
        0%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        € 68,55€ 82,95 10+ In stock
        • -5% Purchase 4 for only € 78,80 per piece

        Buy now, pay later

        • We ship to
        • Ordered now, shipped tomorrow
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        Product description

        Highlights

        • Vented cast aluminum chassis for optimum strength and low compression
        • Geometrically reinforced aluminum cone for optimum piston operation and reduced break-up
        • Soft low damping rubber surround for improved transient response
        • Non-conducting fiber glass voice coil former for minimum damping
        • Extended copper sleeve on pole piece for low inductance and low distortion
        • CCAW voice coil for reduced moving mass
        • Long life silver lead wires
        • Vented pole piece for reduced compression



        Product details

        SB Acoustics SB15NBAC30-8 5" Black Aluminum Cone Mid-bass



        The SB15NBAC30-8 Black Aluminum Cone Mid-bass features: Rohacell®/Carbon fiber sandwich cone for optimized stiffness/damping ratio. Vented cast aluminum chassis for optimum strength and low compression and low damping rubber surround for improved transient response. Non-conducting fiber glass voice coil former for minimum damping. Extended copper sleeve on pole piece for low inductance and low distortion. CCAW voice coil for reduced moving mass and long life silver lead wires. Vented pole piece for reduced compression.

        Show more

        Specifications

        Article number
        SB15NBAC30-8
        Woofer Series
        NBAC Series
        Woofer Type
        Midwoofer
        Nominal Diameter
        5"
        Power Handling (RMS)
        50 Watts
        Impedance (Z)
        8 ohms
        Sensitivity (SPL at 1m / 2.83V)
        85.5 dB
        Voice Coil Diameter
        1.2"
        DC Resistance (Re)
        5.7 ohms
        Voice Coil Inductance (Le)
        0.14 mH
        Resonant Frequency (Fs)
        35.5 Hz
        Mechanical Q (Qms)
        4.22
        Electromagnetic Q (Qes)
        0.41
        Total Q (Qts)
        0.37
        Diaphragm Mass Inc. Airload (Mms)
        10 g
        Mechanical Compliance of Suspension (Cms)
        1.81 mm/N
        Surface Area of Cone (Sd)
        82 cm2
        BL Product (BL)
        5.7 Tm
        Compliance Equivalent Volume (Vas)
        0.6 ft.³
        Maximum Linear Excursion (Xmax)
        5 mm

        Show more
