        SB15MFC30-8 Polypropylene Bass-midwoofer

        SB Acoustics SB15MFC30-8 Polypropylene Bass-midwoofer

        €68,45

        10+ In stock

        Add to cart

        SB Acoustics SB15MFC30-8 Polypropylene Bass-midwoofer

        0 reviews
        0 from 5
        0 reviews
        5 stars
        0%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: SB Acoustics
        Show all Mid-range woofer
        5'' | 8 Ω
        SB15MFC30-8 Polypropylene Bass-midwoofer
        SB15MFC30-8 Polypropylene Bass-midwoofer
        SB15MFC30-8 Polypropylene Bass-midwoofer
        SB15MFC30-8 Polypropylene Bass-midwoofer
        SB15MFC30-8 Polypropylene Bass-midwoofer
        SB15MFC30-8 Polypropylene Bass-midwoofer
        SB15MFC30-8 Polypropylene Bass-midwoofer
        SB15MFC30-8 Polypropylene Bass-midwoofer
        SB15MFC30-8 Polypropylene Bass-midwoofer
        SB15MFC30-8 Polypropylene Bass-midwoofer
        SB15MFC30-8 Polypropylene Bass-midwoofer
        SB15MFC30-8 Polypropylene Bass-midwoofer
        SB15MFC30-8 Polypropylene Bass-midwoofer
        SB15MFC30-8 Polypropylene Bass-midwoofer
        € 56,57€ 68,45 10+ In stock
        • -5% Purchase 4 for only € 65,03 per piece
        +-
        Add to cart

        Buy now, pay later

        • We ship to
        • Same day shipping
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        SB15MFC30-8 Polypropylene Bass-midwoofer
        SB15MFC30-8 Polypropylene Bass-midwoofer
        SB15MFC30-8 Polypropylene Bass-midwoofer
        SB15MFC30-8 Polypropylene Bass-midwoofer
        SB15MFC30-8 Polypropylene Bass-midwoofer
        SB15MFC30-8 Polypropylene Bass-midwoofer
        SB15MFC30-8 Polypropylene Bass-midwoofer
        SB15MFC30-8 Polypropylene Bass-midwoofer
        SB15MFC30-8 Polypropylene Bass-midwoofer
        SB15MFC30-8 Polypropylene Bass-midwoofer
        SB15MFC30-8 Polypropylene Bass-midwoofer
        SB15MFC30-8 Polypropylene Bass-midwoofer
        SB15MFC30-8 Polypropylene Bass-midwoofer
        SB15MFC30-8 Polypropylene Bass-midwoofer
        SB15MFC30-8 Polypropylene Bass-midwoofer
        SB15MFC30-8 Polypropylene Bass-midwoofer

        Pros and cons

        According to our specialists
        • Vented cast aluminium chassis for optimum strength and low compression

        Product description SB Acoustics SB15MFC30-8 Bass-midwoofer

        The SB15MFC30-8 is a 8-ohm 5-inch mid-woofer from SB Acoustics. It has a mineral filled polypropylene (PP) cone, a vented cast aluminum chassis, and a soft low damping rubber surround.



        Highlights

        • Vented cast aluminium chassis for optimum strength and low compression
        • Mineral filled PP-cone made in-house
        • Soft low damping rubber surround for improved transient response
        • Non-conducting fibre glass voice coil former for minimum damping
        • Extended copper sleeve on pole piece for low inductance and low distortion
        • CCAW voice coil for reduced moving mass
        • Long life silver lead wires
        • Vented pole piece for reduced compression



        Product details

        SB Acoustics SB15MFC30-8 Polypropylene Bass-midwoofer



        The SB Acoustics SB15MFC30-8 is a well-made and versatile woofer that can be used in a variety of audio applications. It is known for its smooth, accurate sound reproduction and its ability to handle high power levels. It has a frequency response of 35-2000 Hz, a sensitivity of 89 dB, and an impedance of 8 ohms. The woofer is made with a mineral-filled polypropylene cone, a rubber surround, and a CCAW voice coil. It has a vented cast aluminum chassis for strength and low compression.



        The SB Acoustics SB15MFC30-8 is a well-made and versatile woofer that can be used in a variety of audio applications. It is known for its smooth, accurate sound reproduction and its ability to handle high power levels.

        Show more

        Specifications

        Article number
        SB15MFC30-8
        EAN
        8785256847938
        Woofer Type
        Bass-midwoofer
        Nominal Diameter
        5 inch
        Power Handling (RMS)
        50 Watts
        Power Handling (max)
        50 Watt
        Impedance (Z)
        8 Ohm
        Sensitivity (SPL at 1m / 2.83V)
        87 dB
        Frequency Response
        100-2000 Hz
        Voice Coil Diameter
        30.5 mm
        Magnet Weight
        0.54 kg
        DC Resistance (Re)
        5.7 Ohm
        Voice Coil Inductance (Le)
        0.14 mH
        Resonant Frequency (Fs)
        39 Hz
        Mechanical Q (Qms)
        4.4
        Electromagnetic Q (Qes)
        0.4
        Total Q (Qts)
        0.37
        Diaphragm Mass Inc. Airload (Mms)
        9.0 g
        Mechanical Compliance of Suspension (Cms)
        1.85 mm/N
        Surface Area of Cone (Sd)
        82 cm2
        BL Product (BL)
        5.6 N/A
        Compliance Equivalent Volume (Vas)
        17.7 liters
        Maximum Linear Excursion (Xmax)
        5 mm
        Driver's Mechanical Losses (Rms)
        0.5 kg/s
        Basket / Frame Material
        Vented cast aluminium
        Overall Outside Diameter
        150 mm
        Overall Depth
        79 mm
        # Mounting Holes
        4
        Mounting Hole Diameter
        4.3 mm

        Show more
