        SB12MNRX25-4 4" Midrange Woofer

        SB12MNRX25-4 4" Midrange Woofer


        SB Acoustics SB12MNRX25-4 4" Midrange Woofer

        1 reviews
        5 from 5
        1 reviews
        5 stars
        4 stars
        3 stars
        2 stars
        1 star
        View all reviews
        € 49,55€ 59,95 10+ In stock
        • -5% Purchase 4 for only € 56,95 per piece

        Buy now, pay later

        • We ship to
        • Ordered now, shipped on Monday
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        Product description


        • Proprietary cone material with natural fibres made in-house
        • Shortened voice coil optimized for pure midrange reproduction
        • High damping Butyl rubber surround for non-resonant sound character
        • Vented pole piece for reduced compression
        • Vented cast aluminium chassis for optimum strength and low compression
        • CCAW voice coil for reduced moving mass
        • Long life silver lead wires
        • Non-conducting fibre glass coil former for minimum damping


        Product details

        SB Acoustics SB12MNRX25-4 4" Midrange Woofer


        SB Acoustics Midrange Woofer is an excellent SB Acoustics Ferrite magnet midrange/midwoofer, featuring a high efficiency foam surround. Fitted with a proprietary composition paper cone, 1" voice coil. Very open cast frame for minimal reflections. Fs 61Hz, good level extended response up to 5KHz.

        Show more


        Article number
        Woofer Series
        NRX Series
        Woofer Type
        Nominal Diameter
        Power Handling (RMS)
        30 Watts
        Impedance (Z)
        4 ohms
        Sensitivity (SPL at 1m / 2.83V)
        88.5 dB
        Voice Coil Diameter
        DC Resistance (Re)
        3.2 ohms
        Voice Coil Inductance (Le)
        0.14 mH
        Resonant Frequency (Fs)
        58 Hz
        Mechanical Q (Qms)
        Electromagnetic Q (Qes)
        Total Q (Qts)
        Diaphragm Mass Inc. Airload (Mms)
        4.9 g
        Mechanical Compliance of Suspension (Cms)
        1.55 mm/N
        Surface Area of Cone (Sd)
        50.3 cm2
        BL Product (BL)
        3.7 Tm
        Compliance Equivalent Volume (Vas)
        0.19 ft.³
        Maximum Linear Excursion (Xmax)
        2.3 mm

        Show more

        5 of 5
        Very good build quality with CNC machined parts.
        By Guntars S. on 11 May 2021
