        MW16P-12 Bass-midwoofer

        SB Acoustics MW16P-12 Bass-midwoofer

        €174,95

        6 In stock

        Add to cart

        SB Acoustics MW16P-12 Bass-midwoofer

        0 reviews
        0 from 5
        0 reviews
        5 stars
        0%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: SB Acoustics
        Show all New products
        6.5" | 12 Ω
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        € 144,59€ 174,95 6 In stock
        • -0% Purchase 4 for only € 174,95 per piece
        +-
        Add to cart

        Buy now, pay later

        • We ship to
        • Ordered now, shipped tomorrow
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer
        MW16P-12 Bass-midwoofer

        Pros and cons

        According to our specialists
        • Flexibility thanks to 12 Ohm impedance

        Product description SB Acoustics MW16P-12 Bass-midwoofer

        The SB Acoustics Satori MW16P-12 is a high-end 6.5" midwoofer designed for discerning audiophiles and speaker builders seeking premium performance. With a focus on low distortion, natural tonal balance, and advanced motor design, this 12-ohm driver is ideal for high-fidelity speaker applications where clarity and precision are paramount.



        Highlights of the SB Acoustics Satori MW16P-12

        • 6.5" Egyptian Papyrus cone for superior damping and natural sound reproduction
        • Vented cast aluminum chassis and neodymium motor system for low distortion
        • Extended copper sleeve on the pole piece to reduce inductance and distortion
        • CCAW voice coil and advanced Bimax spider for improved linearity and transient response



        Product details SB Acoustics Satori MW16P-12

        SB Acoustics Satori MW16P-12 6.5" Midwoofer



        The Satori MW16P-12 by SB Acoustics is part of their flagship line and combines carefully engineered acoustic and mechanical elements to deliver audiophile-grade performance. Featuring a proprietary cone crafted from Egyptian Papyrus™ fibers, the MW16P-12 offers excellent internal damping for a clean and natural midrange. The vented aerodynamic cast aluminum chassis minimizes compression while enhancing structural strength. The powerful low-distortion neodymium motor is optimized with an extended copper sleeve on the pole piece, reducing inductance and minimizing distortion. The non-conductive fiberglass voice coil former, combined with a CCAW (copper-clad aluminum wire) voice coil, results in reduced moving mass and superior transient response. The soft, low-damping rubber surround and advanced Bimax spider further improve linearity and control over cone movement.



        With a free-air resonance (Fs) of 30.6 Hz, sensitivity of 85 dB, and a linear excursion of 12.4 mm (p-p), the MW16P-12 is engineered for accurate low-frequency response and dynamic range. It is ideally suited for high-end 2-way and 3-way designs, particularly in applications that require precise detail and low coloration across the midrange spectrum.

        Show more

        Specifications

        Article number
        MW16P-12
        EAN
        9501934468238
        Woofer Series
        SB Acoustics Satori series
        Woofer Type
        Bass-Midwoofer
        Nominal Diameter
        6.5"
        Power Handling (RMS)
        50 Watts
        Impedance (Z)
        12 Ω
        Sensitivity (SPL at 1m / 2.83V)
        85 dB
        Frequency Response
        35 - 2.000 Hz
        Voice Coil Diameter
        35.5 mm
        DC Resistance (Re)
        10 Ω
        Voice Coil Inductance (Le)
        0.19 mH
        Resonant Frequency (Fs)
        30.6 Hz
        Mechanical Q (Qms)
        4.81
        Electromagnetic Q (Qes)
        0.40
        Total Q (Qts)
        0.37
        Diaphragm Mass Inc. Airload (Mms)
        11.5 g
        Mechanical Compliance of Suspension (Cms)
        2.35 mm/N
        Surface Area of Cone (Sd)
        119 cm²
        BL Product (BL)
        7.4 Tm
        Compliance Equivalent Volume (Vas)
        47.3 Liters
        Maximum Linear Excursion (Xmax)
        12.4 mm
        Driver's Mechanical Losses (Rms)
        0.46 kg/s
        Surround Material
        Rubber
        Voice Coil Former
        Fiber glass
        Magnet Material
        Neodymium
        Overall Outside Diameter
        165 mm
        Overall Depth
        86.1 mm
        Baffle Cutout Diameter
        140.1 mm
        Bolt Circle Diameter
        153.5 mm
        # Mounting Holes
        6
        Mounting Hole Diameter
        4.3 mm

        Show more
