        201TN 0.8" Dome tweeter 8 ohms

        REDCATT 201TN 0.8" Dome tweeter 8 ohms

        €8,95

        Out of stock

        Add to cart

        REDCATT 201TN 0.8" Dome tweeter 8 ohms

        0 reviews
        0 from 5
        0 reviews
        5 stars
        0%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: REDCATT
        Show all Dome tweeter
        0.8" | 8 Ω
        201TN 0.8" Dome tweeter 8 ohms
        201TN 0.8" Dome tweeter 8 ohms
        201TN 0.8" Dome tweeter 8 ohms
        201TN 0.8" Dome tweeter 8 ohms
        201TN 0.8" Dome tweeter 8 ohms
        201TN 0.8" Dome tweeter 8 ohms
        € 7,40€ 8,95 Out of stock
        +-
        Add to cart

        Buy now, pay later

        • We ship to
        • Back in stock soon
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        201TN 0.8" Dome tweeter 8 ohms
        201TN 0.8" Dome tweeter 8 ohms
        201TN 0.8" Dome tweeter 8 ohms
        201TN 0.8" Dome tweeter 8 ohms
        201TN 0.8" Dome tweeter 8 ohms
        201TN 0.8" Dome tweeter 8 ohms

        Product description REDCATT 201TN Dome Tweeter

        The REDCATT 201TN is a compact 0.8" dome tweeter with 8 ohm impedance, neodymium motor, aluminium construction details and a wide-band response for compact loudspeaker designs.



        Highlights of the REDCATT 201TN

        • 0.8" dome tweeter with 8 ohm rated impedance
        • Neodymium magnet for a compact, lightweight motor structure
        • 10 W AES power handling, 20 W continuous power and 40 W peak power
        • 86 dB sensitivity with a 1900 Hz resonance frequency
        • Bare tweeter design for use with a custom waveguide or integrated baffle waveguide
        • Suitable for tabletop studio monitors, bookshelf speakers, TV bars and micro line-arrays



        Product details REDCATT 201TN

        REDCATT 201TN 0.8" Dome Tweeter 8 Ohm



        The REDCATT 201TN is a compact tweeter designed for high-frequency use in compact loudspeaker projects. Its neodymium magnet helps keep the driver light and space-efficient, while the aluminium former and CCAW winding support a practical balance of performance and low moving mass.



        This dome tweeter is supplied as a bare tweeter, making it well suited for integration into your own waveguide or into a baffle with an integrated waveguide. That gives designers flexibility when tuning dispersion and acoustic loading for custom speaker designs.



        With a resonance frequency of 1900 Hz and a wide-band frequency response, the 201TN helps simplify crossover work in compact systems. It handles 10 W AES power, 20 W continuous power and 40 W peak power, with a sensitivity of 86 dB.



        The 201TN is a practical choice for tabletop studio monitors, prosumer products, bookshelf speakers, TV bars, compact 2-way PA concepts and micro line-arrays. Its 19.70 mm mounting depth and 0.04 kg net weight make it easy to integrate where space and weight are limited.

        Show more

        Specifications

        Article number
        201TN
        EAN
        9502652947852

        Show more

        Reviews

        0 reviews
        Review this product

        There are no reviews written yet about this product..

        201TN 0.8" Dome tweeter 8 ohms
        € 7,40
        € 8,95
        201TN 0.8" Dome tweeter 8 ohms
        Out of stock
        Add to cart
