        Ultimate UW1054 10" Subwoofer 4 Ohm

        Morel Ultimate UW1054 10" Subwoofer 4 Ohm

        €649,95

        1 In stock

        Add to cart

        Morel Ultimate UW1054 10" Subwoofer 4 Ohm

        0 reviews
        0 from 5
        0 reviews
        5 stars
        0%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: Morel
        Show all Subwoofer
        10" | 4 Ω
        Ultimate UW1054 10" Subwoofer 4 Ohm
        Ultimate UW1054 10" Subwoofer 4 Ohm
        Ultimate UW1054 10" Subwoofer 4 Ohm
        Ultimate UW1054 10" Subwoofer 4 Ohm
        Ultimate UW1054 10" Subwoofer 4 Ohm
        Ultimate UW1054 10" Subwoofer 4 Ohm
        Ultimate UW1054 10" Subwoofer 4 Ohm
        Ultimate UW1054 10" Subwoofer 4 Ohm
        Ultimate UW1054 10" Subwoofer 4 Ohm
        Ultimate UW1054 10" Subwoofer 4 Ohm
        Ultimate UW1054 10" Subwoofer 4 Ohm
        Ultimate UW1054 10" Subwoofer 4 Ohm
        Ultimate UW1054 10" Subwoofer 4 Ohm
        Ultimate UW1054 10" Subwoofer 4 Ohm
        € 537,15€ 649,95 1 In stock
        • -5% Purchase 4 for only € 617,45 per piece
        +-
        Add to cart

        Buy now, pay later

        • We ship to
        • Ordered now, shipped on Monday
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        Ultimate UW1054 10" Subwoofer 4 Ohm
        Ultimate UW1054 10" Subwoofer 4 Ohm
        Ultimate UW1054 10" Subwoofer 4 Ohm
        Ultimate UW1054 10" Subwoofer 4 Ohm
        Ultimate UW1054 10" Subwoofer 4 Ohm
        Ultimate UW1054 10" Subwoofer 4 Ohm
        Ultimate UW1054 10" Subwoofer 4 Ohm
        Ultimate UW1054 10" Subwoofer 4 Ohm
        Ultimate UW1054 10" Subwoofer 4 Ohm
        Ultimate UW1054 10" Subwoofer 4 Ohm
        Ultimate UW1054 10" Subwoofer 4 Ohm
        Ultimate UW1054 10" Subwoofer 4 Ohm
        Ultimate UW1054 10" Subwoofer 4 Ohm
        Ultimate UW1054 10" Subwoofer 4 Ohm
        Ultimate UW1054 10" Subwoofer 4 Ohm
        Ultimate UW1054 10" Subwoofer 4 Ohm

        Product description Morel UW1054 Subwoofer

        The Morel UW 1054 is a 10” subwoofer from the Ultimate Subwoofer Line by Morel. It has a massive 5.1" aluminum hexatech voice coil that can handle extreme amounts of power. The subwoofer has a paper/carbon conus and is 10" in size. It has an impedance of 4 Ohm.



        Highlights

        • Uniflow™aluminum diecast chassis
        • High-flux double ferrite magnet system
        • 5.1" Hexatech™aluminum voice coil with 1-1/2" winding length
        • Very high Xmax for extended bass response
        • One piece paper cone/center dome
        • Accucenter™ self-centering cone assembly
        • PFS™ Progression Field Symmetry spider/surround engineering



        Product details

        Morel Ultimate UW1054 10" Subwoofer 4 Ohm



        The Morel Ultimate UW1054 is a high-performance subwoofer that is designed for demanding audio enthusiasts. It features a 10-inch paper cone with a 5.1-inch aluminum voice coil, which is powered by a double ferrite magnet system. This combination of components allows the UW1054 to produce deep, accurate bass with minimal distortion.



        The 10” UW1054 is also built to last. It features a die-cast aluminum chassis that is both lightweight and rigid, and it is protected by a dustcap and rubber surround. The subwoofer is also equipped with a Progressive Field Symmetry spider, which helps to improve its linearity and reduce distortion.



        In terms of performance, the UW1054 is capable of delivering up to 500 watts of RMS power and 1,500 watts of peak power. This makes it a good choice for a variety of applications, including home theater, car audio, and professional sound reinforcement.

        Show more

        Specifications

        Article number
        UW1054
        EAN
        8785256847679
        Woofer Series
        Morel Ultimate Subwoofer series
        Woofer Type
        Subwoofer
        Nominal Diameter
        10"
        Power Handling (RMS)
        500 Watts
        Power Handling (max)
        1500 watts (10 ms)
        Impedance (Z)
        4 Ω
        Sensitivity (SPL at 1m / 2.83V)
        88 dB
        Frequency Response
        22 - 1.500 Hz
        Voice Coil Diameter
        130 mm
        DC Resistance (Re)
        3.55 Ω
        Voice Coil Inductance (Le)
        1.0 mH
        Mechanical Q (Qms)
        1.43
        Electromagnetic Q (Qes)
        0.35
        Total Q (Qts)
        0.29
        Diaphragm Mass Inc. Airload (Mms)
        102 g
        Surface Area of Cone (Sd)
        346 cm²
        BL Product (BL)
        11.8 Tm
        Compliance Equivalent Volume (Vas)
        86.5 Liters
        Maximum Linear Excursion (Xmax)
        +/- 12 mm
        Driver's Mechanical Losses (Rms)
        9.78 kg/s
        Voice Coil Wire Material
        Hexatech™ Aluminum
        Voice Coil Former
        Aluminium
        Magnet Material
        Ferrite
        Overall Outside Diameter
        263 mm
        Overall Depth
        148.5 mm
        Baffle Cutout Diameter
        241 mm
        Bolt Circle Diameter
        253 mm
        # Mounting Holes
        6
        Mounting Hole Diameter
        5 mm

        Show more
