        Integra 624 Hybrid Series 6" Point Source Coaxial Full-Range

        Morel Integra 624 Hybrid Series 6" Point Source Coaxial Full-Range

        €229,95 €279,95

        10+ In stock

        Add to cart

        Morel Integra 624 Hybrid Series 6" Point Source Coaxial Full-Range

        1 reviews
        5 from 5
        1 reviews
        5 stars
        100%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: Morel
        6'' | 4 Ω
        Integra 624 Hybrid Series 6" Point Source Coaxial Full-Range
        Integra 624 Hybrid Series 6" Point Source Coaxial Full-Range
        Integra 624 Hybrid Series 6" Point Source Coaxial Full-Range
        Integra 624 Hybrid Series 6" Point Source Coaxial Full-Range
        Integra 624 Hybrid Series 6" Point Source Coaxial Full-Range
        Integra 624 Hybrid Series 6" Point Source Coaxial Full-Range
        Integra 624 Hybrid Series 6" Point Source Coaxial Full-Range
        Integra 624 Hybrid Series 6" Point Source Coaxial Full-Range
        Integra 624 Hybrid Series 6" Point Source Coaxial Full-Range
        Integra 624 Hybrid Series 6" Point Source Coaxial Full-Range
        Integra 624 Hybrid Series 6" Point Source Coaxial Full-Range
        Integra 624 Hybrid Series 6" Point Source Coaxial Full-Range
        Integra 624 Hybrid Series 6" Point Source Coaxial Full-Range
        € 231,36
        € 279,95
        € 190,04€ 229,95 10+ In stock
        • -5% Purchase 4 for only € 218,45 per piece
        € 229,95
        +-
        Add to cart
        🔒 Secure payment
        MastercardVisaBank TransferCarte BancaireApple PayGoogle Paypaypal

        Buy now, pay later

        • We ship to
        • Ordered now, shipped on Monday
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        Integra 624 Hybrid Series 6" Point Source Coaxial Full-Range
        Integra 624 Hybrid Series 6" Point Source Coaxial Full-Range
        Integra 624 Hybrid Series 6" Point Source Coaxial Full-Range
        Integra 624 Hybrid Series 6" Point Source Coaxial Full-Range
        Integra 624 Hybrid Series 6" Point Source Coaxial Full-Range
        Integra 624 Hybrid Series 6" Point Source Coaxial Full-Range
        Integra 624 Hybrid Series 6" Point Source Coaxial Full-Range
        Integra 624 Hybrid Series 6" Point Source Coaxial Full-Range
        Integra 624 Hybrid Series 6" Point Source Coaxial Full-Range
        Integra 624 Hybrid Series 6" Point Source Coaxial Full-Range
        Integra 624 Hybrid Series 6" Point Source Coaxial Full-Range
        Integra 624 Hybrid Series 6" Point Source Coaxial Full-Range
        Integra 624 Hybrid Series 6" Point Source Coaxial Full-Range
        Integra 624 Hybrid Series 6" Point Source Coaxial Full-Range

        Pros and cons

        According to our specialists
        • Hybrid Neodynium & Ferrite magnet
        • Large 54 mm Hexatech voice coil with hybrid neodymium/ferrite magnet system
        • Coaxial point-source design for coherent sound reproduction

        Product description Morel Integra 624 Coaxial Woofer

        The Morel Integra 624 is a 160.2 mm Hybrid Integra coaxial full-range driver with a 4 ohm tweeter and woofer section, combining a hand-coated soft dome, composite paper cone, large Hexatech aluminum voice coil and time-aligned point-source configuration.





        Highlights of the Morel Integra 624

        • Hybrid Integra coaxial design with time-aligned tweeter-woofer configuration
        • Acuflex hand-coated soft dome tweeter and composite paper woofer cone
        • 54 mm Hexatech aluminum woofer voice coil with Hybrid neodymium/ferrite magnet system
        • 89 dB tweeter sensitivity and 90.3 dB woofer sensitivity at 2.83 V/1 m
        • Aluminum die-cast chassis with 140 mm cutout diameter and 63 mm basket depth





        Product details Morel Integra 624

        Morel Integra 624 160.2 mm Hybrid Integra Coaxial Full-Range Driver 4 Ohm



        The Morel Integra 624 is built as a high-quality raw driver for demanding audio components projects where a compact point-source layout is preferred. Its coaxial architecture places the soft dome tweeter in a time-aligned tweeter-woofer configuration, helping the driver behave as a coherent full-range woofer solution within its intended operating range.



        The tweeter section uses a 28 mm voice coil and Acuflex hand-coated soft dome, while the woofer section features a large 54 mm Hexatech aluminum voice coil. Both sections are rated at 4 ohm nominal impedance. The tweeter has 89 dB sensitivity, and the woofer reaches 90.3 dB sensitivity, measured at 2.83 V/1 m. Transient power handling is specified at 200 W for the tweeter and 500 W for the woofer.



        Morel combines a composite paper cone, Hybrid neodymium/ferrite magnet system, Uniflow design and aluminum die-cast chassis to support controlled performance and robust mechanical construction. For builders comparing compact high-performance woofers, the Integra 624 also offers practical installation dimensions: 160.2 mm overall diameter, 69 mm overall height, 63 mm basket depth and a 140 mm cutout diameter.



        The woofer’s Thiele-Small parameters include a 58 Hz resonant frequency, 0.35 total Q, 15.35 L equivalent compliance volume and 119 cm² effective piston area. Linear excursion is ±3.0 mm for the woofer and ±0.25 mm for the tweeter. Six mounting holes are positioned on a 152 mm diameter circle at 60 degree intervals, with 4.2 mm inner hole diameter for secure installation.

        Show more

        Specifications

        Article number
        Integra 624
        EAN
        0848864043654
        Woofer Type
        Coaxial speaker
        Nominal Diameter
        6"
        Power Handling (RMS)
        80 Watt
        Impedance (Z)
        4 Ω
        Sensitivity (SPL at 1m / 2.83V)
        90.3 dB
        Frequency Response
        55 - 20.000 Hz
        Voice Coil Diameter
        Woofer 54 mm + Tweeter 28 mm
        DC Resistance (Re)
        Woofer 3.68 Ω and Tweeter 3.73 Ω
        Voice Coil Inductance (Le)
        Woofer 0.53 mH and Tweeter 0.84 mH
        Resonant Frequency (Fs)
        58 Hz
        Mechanical Q (Qms)
        1.84
        Electromagnetic Q (Qes)
        W: 0.43 T: 2.72
        Total Q (Qts)
        0.35
        Diaphragm Mass Inc. Airload (Mms)
        9.62 g
        Moving Mass Of Diaphragm (Mmd)
        9.62 g
        Mechanical Compliance of Suspension (Cms)
        0.77 mm/N
        Surface Area of Cone (Sd)
        119 cm²
        BL Product (BL)
        5.4 Tm
        Compliance Equivalent Volume (Vas)
        15.35 L
        Maximum Linear Excursion (Xmax)
        3 mm
        Driver's Mechanical Losses (Rms)
        1.9 Kg/s
        Cone / Diaphragm Material
        Aluminum
        Overall Outside Diameter
        160.2 mm
        Overall Depth
        69 mm
        Baffle Cutout Diameter
        140 mm
        # Mounting Holes
        6
        Mounting Hole Diameter
        4.2 mm
