        Classic Advanced CAT 308 Dome Tweeter

        Classic Advanced CAT 308 Dome Tweeter

        €99,95

        Morel Classic Advanced CAT 308 Dome Tweeter

        5 reviews
        5 from 5
        5 reviews
        5 stars
        100%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: Morel
        € 82,60€ 99,95 3 In stock10+ expected on 30-04-2024
        • -5% Purchase 4 for only € 94,95 per piece

        Buy now, pay later

        • We ship to
        • Ordered now, shipped today
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        Product description

        A new version of Morel's classic MDT-30, the CAT308 is a very fast tweeter capable of high dynamic range without SPL compression.



        Highlights

        • 104 mm aluminum faceplate
        • Large Hexatech™ aluminum voice coil
        • Replaceable Acuflex™ dome/coil assembly
        • Ferrofluid cooled
        • High power handling
        • Sturdy gold plated input tags



        Product details

        Morel Classic Advanced CAT 308 1" Dome Tweeter



        A new version of Morel's classic MDT-30, the CAT308 is a very fast tweeter capable of high dynamic range without SPL compression. It features a single magnet system vented into a damped rear chamber that lowers resonance. The ferrofluid cooled aluminum voice coil contributes to the CAT308's low distortion and exceptionally smooth response. 1-1/8" treated soft dome.

        Show more

        Specifications

        Article number
        CAT308
        Tweeter Type
        Soft Dome
        Tweeter Series
        Classic Advanced Series
        Cone / Dome Diameter
        25 mm | 1"
        Power Handling (RMS)
        200 Watts
        Impedance (Z)
        8 Ω
        Sensitivity (SPL at 1m / 2.83V)
        90 dB
        Frequency Response
        1,600 to 20,000 Hz
        Resonant Frequency (Fs)
        700 Hz
        DC Resistance (Re)
        5.2 ohms
        Voice Coil Inductance (Le)
        0.09 mH
        Overall Outside Diameter
        4.09"
        Cutout Diameter
        2.83"
        Depth
        1.69"

        Show more

        5 of 5
        He utilizado el tweeter para cambiar y mejorar los que tenía en mis altavoces. El cambio ha sido increíble. Ojalá lo hubiera hecho antes. Ya conocía la marca y lo tenía claro.
        By Camilo on 5 November 2023
        5 of 5
        Perfekt klar, luftig und schnell. Ohne jegliche Kompression. Nie anstrengend und trotz enormer Leistungsfähigkeit auch im Leisen eine zarte Ansprache. Macht aus meiner Visaton Concorde ( ersetzt KE25SC ) endlich einen wohlgefälligen Lautsprecher.
        By Michael S. on 6 April 2023
