Markaudio Alpair-10 Grey 6" Full-range Woofer

Delivery time: 1-4 business days

  • Article code: Alpair-10 Grey
  • Stock: >10 In stock

This Alpair 10 Gen. 3 is the latest model in a development line designed to extend the performance of mid-sized Markaudio full-range emitters.

Price for one driver:

114,95 € 97,71 Incl. 21% VAT

  • Buy 4 for €109,20 each and save 5% Sale 5%

Add to wishlist

  • Low international shipping rates Tooltip

    Find all shipping rates and free shipping thresholds here

  • Same day shipping
  • 45-day money back guarantee
  • International payment options

Product description

Markaudio Alpair-10 Grey 6" Full-range Woofer

This Alpair 10 Gen. 3 is the latest model in a development line designed to extend the performance of mid-sized Markaudio full-range emitters. This generation of Alpair 10 utilizes a new ultra-thin wall coil. Together with further modifications to the cone, this latest model delivers usable frequency range up to 25-kHz while retaining its “purist” single cone design.



Highlights

  • Ultra thin wall coil
  • Aluminum Cone
  • Latest model, 3rd generation
  • Excursion Arrestor sounds when exceeding excursion limits



Product Details

MarkAudio Alpair-10 Grey 6" Full-range Woofer



This Alpair 10 Gen. 3 is the latest model in a development line designed to extend the performance of mid-sized Markaudio full-range emitters. This generation of Alpair 10 utilizes a new ultra-thin wall coil. Together with further modifications to the cone, this latest model delivers usable frequency range up to 25-kHz while retaining its “purist” single cone design.



This driver retains the multi-form cone technology with a new more efficient profile giving improved high range performance. Design modifications to the Gen.3ʻs coneʼs neck, together with the lighter coil deliver a better off axis response in the 15-degree region. Central stereo imaging and box angle placements benefit from these improvements.



The Gen.3 version houses an “Arrestor” in the magnet sub-assembly, a device that helps to avoid damage from over-load situations. For those users who like to add low frequency gain, the Gen.3ʼs power-train (cone, coil and suspensions) design retains the “long throw” design feature. While this driver is not designed for continuous heavy loads, the Gen.3 is capable of handling variable bass load outputs from from most typical and popular forms of music.



The Gen.3 retains the audible smoothness of its predecessors while adding usable bandwidth, improved SPL and additional scope for optimizing room placement of the box system.

Specifications

Specifications for: Alpair-10 Grey 6" Full-range Woofer

  • Woofer Series Specific woofer production line of the manufacturer. Alpair Series
  • Woofer Type The driver type for example subwoofer, mid-woofer, full range or coaxial woofer. Full-range
  • Nominal Diameter The approximate diameter of the driver, measured in inches. 6"
  • Power Handling (RMS) The average power handling capability of a driver (coil) in electric power (watts) for a long period of time without damaging the driver. RMS stands for Root Mean Square 30 Watts
  • Power Handling (max) The maximum electrical power that a woofer (coil) can handle for a short period of time before it is damaged.
  • View all specifications
  • Continuous Program Power
  • Impedance 8 ohms
  • Sensitivity 87.9 dB 2.83V/1m
  • Frequency Response
  • Voice Coil Diameter 0.98"
  • Magnet Weight
  • DC Resistance (Re) 7.2 ohms
  • Voice Coil Inductance (Le)
  • Resonant Frequency (Fs) 35 Hz
  • Mechanical Q (Qms) 2.53
  • Electromagnetic Q (Qes) 0.41
  • Total Q (Qts) 0.35
  • Diaphragm Mass Inc. Airload (Mms) 7.96g
  • Moving Mass Of Diaphragm (Mmd)
  • Mechanical Compliance of Suspension (Cms) 2.54 mm/N
  • Surface Area of Cone (Sd) 50.24 cm²
  • Volume of Displacement (Vd)
  • BL Product (BL) 5.6 Tm
  • Compliance Equivalent Volume (Vas) 0.99 ft.³
  • Maximum Linear Excursion (Xmax) 4.4 mm
  • Driver's Mechanical Losses (Rms)
  • Cone / Diaphragm Material
  • Surround Material
  • Voice Coil Wire Material
  • Voice Coil Former
  • Dual Voice Coil
  • Basket / Frame Material
  • Magnet Material
  • Shielded
  • Overall Outside Diameter 6.46"
  • Overall Depth 3.12"
  • Baffle Cutout Diameter 5.83"
  • Bolt Circle Diameter
  • # Mounting Holes 4
  • Mounting Hole Diameter
  • Sealed Volume
  • Sealed F3
  • Vented Volume
  • Vented F3
