        Product description

        The HiVi D10.8 represents a design in which the voice coil is positioned over an undercut central pole piece with a large thermally stabilized neodymium magnet at the bottom and a high energy ceramic magnet on the top.



        Highlights

        • Extreme power handling 100 mm voice coil with a black anodized aluminum former
        • Shielded vented magnet system with a huge Neodymium magnet
        • Fatigue resistant foam surround
        • Long-throw symmetrically driving motor structure
        • Progressive spider with decompressed rear volume
        • High density aluminum die-cast frame



        Product details

        HiVi D10.8 | 10"| Poly Cone Woofer



        The HiVi D10.8 represents a design in which the voice coil is positioned over an undercut central pole piece with a large thermally stabilized neodymium magnet at the bottom and a high energy ceramic magnet on the top. A specially shaped, CNC machined steel cup completes the magnetic structure from the outside, creating a shielded magnet system with symmetrical flux density distribution along the gap. The long-throw voice coil experiences a symmetric driving force that substantially decreases inductance and back electromotive force modulations. The magnet structure is optimized using Finite Element Analysis technique, resulting in a radical improvement of driver linearity. The cone has a shallow, high integrity structure that is extremely rigid and dynamically stable. The large voice coil diameter allows for a more uniform cone movement, delivering clear and accurate reproduction. The vented motor design and high temperature rated voice coil provide a dramatic increase in power handling. D10.8 is an excellent woofer for high power "no compromise" audiophile systems and control monitors. It also may be used as a subwoofer in various configurations.

        Show more

        Specifications

        Article number
        D10.8
        Woofer Series
        D10 Series
        Woofer Type
        Poly Cone Woofer
        Nominal Diameter
        10"
        Power Handling (RMS)
        150 Watts
        Power Handling (max)
        300 Watts
        Impedance (Z)
        8 ohms
        Sensitivity (SPL at 1m / 2.83V)
        90 dB
        Frequency Response
        24 to 2,300 Hz
        Voice Coil Diameter
        4"
        DC Resistance (Re)
        6.5 ohms
        Resonant Frequency (Fs)
        24 Hz
        Mechanical Q (Qms)
        6.84
        Electromagnetic Q (Qes)
        0.44
        Total Q (Qts)
        0.41
        Diaphragm Mass Inc. Airload (Mms)
        75.5g
        Mechanical Compliance of Suspension (Cms)
        0.56 mm/N
        Surface Area of Cone (Sd)
        434 cm²
        BL Product (BL)
        13.4 Tm
        Compliance Equivalent Volume (Vas)
        5.2 ft.³
        Maximum Linear Excursion (Xmax)
        8 mm
        Cone / Diaphragm Material
        Poly
        Surround Material
        Foam
        Voice Coil Wire Material
        CCA
        Voice Coil Former
        Kapton® / Polyimide
        Basket / Frame Material
        Cast Aluminum
        Magnet Material
        Neodymium
        Sealed Volume
        1.93 ft.³
        Sealed F3
        43 Hz
        Vented Volume
        5.71 ft.³
        Vented F3
        24 Hz

        Show more

        5 of 5
        Erg mooie woofer en perfecte communicatie en afhandeling! Bedankt!
        By Alex Bartels on 18 July 2022
        5 of 5
        Top. In einem aperiodisch bedämpften Gehäuse (70 Liter) verbaut.
        By Kurt Burger on 30 May 2022
