        5SMP-8 5-1/4" Surface Mount Poly Cone Bass-midwoofer

        GRS 5SMP-8 5-1/4" Surface Mount Poly Cone Bass-midwoofer

        €29,95

        10+ expected on 19-12-2025

        Add to cart

        GRS 5SMP-8 5-1/4" Surface Mount Poly Cone Bass-midwoofer

        0 reviews
        0 from 5
        0 reviews
        5 stars
        0%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: GRS
        Show all New products
        5¼" | 8 Ω
        5SMP-8 5-1/4" Surface Mount Poly Cone Bass-midwoofer
        5SMP-8 5-1/4" Surface Mount Poly Cone Bass-midwoofer
        5SMP-8 5-1/4" Surface Mount Poly Cone Bass-midwoofer
        5SMP-8 5-1/4" Surface Mount Poly Cone Bass-midwoofer
        5SMP-8 5-1/4" Surface Mount Poly Cone Bass-midwoofer
        5SMP-8 5-1/4" Surface Mount Poly Cone Bass-midwoofer
        € 24,75€ 29,95 Out of stock10+ expected on 19-12-2025
        • -5% Purchase 4 for only € 28,45 per piece
        +-
        Add to cart

        Buy now, pay later

        • We ship to
        • Back in stock soon
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        5SMP-8 5-1/4" Surface Mount Poly Cone Bass-midwoofer
        5SMP-8 5-1/4" Surface Mount Poly Cone Bass-midwoofer
        5SMP-8 5-1/4" Surface Mount Poly Cone Bass-midwoofer
        5SMP-8 5-1/4" Surface Mount Poly Cone Bass-midwoofer
        5SMP-8 5-1/4" Surface Mount Poly Cone Bass-midwoofer
        5SMP-8 5-1/4" Surface Mount Poly Cone Bass-midwoofer

        Product description GRS 5SMP-8 Bass-midwoofer

        Compact and optimized for surface mounting, the GRS 5SMP-8 is a 5-1/4" poly cone woofer designed for clarity and control in midbass performance. Engineered with thoughtful design features like a copper cap and aluminum voice coil former, this driver offers solid performance for DIY speaker projects and compact audio systems.



        Highlights of the GRS 5SMP-8

        • Damped poly cone with rubber surround ensures smooth, low-resonance response
        • Aluminum voice coil former enhances thermal stability and power handling
        • Copper cap reduces inductance and minimizes distortion
        • Low-profile frame with integrated foam gasket is ideal for surface mount designs



        Product details GRS 5SMP-8

        GRS 5SMP-8 Surface Mount Woofer



        The GRS 5SMP-8 is a versatile 5-1/4" 8-ohm woofer tailored for surface mount applications, delivering a usable frequency range from 50 Hz to 2,500 Hz. Its poly cone construction and rubber surround help suppress unwanted resonances, while the vented pole piece and aluminum voice coil former support effective thermal management. A copper cap on the motor structure further reduces voice coil inductance, improving high-frequency clarity and lowering harmonic distortion. With an SPL of 86.4 dB at 2.83V/1m and an RMS power handling of 35 watts, the 5SMP-8 is well-suited for compact full-range systems, line arrays, or midbass augmentation in 2-way speaker designs. Its integrated foam gasket also helps achieve a tight acoustic seal during cabinet mounting.

        Show more

        Specifications

        Article number
        5SMP-8
        EAN
        0848864079813
        Woofer Type
        Bass-midwoofer
        Power Handling (RMS)
        35 Watts
        Impedance (Z)
        8 Ohm
        Sensitivity (SPL at 1m / 2.83V)
        86.4 dB
        Frequency Response
        50 – 2,500 Hz
        Voice Coil Diameter
        26 mm
        DC Resistance (Re)
        6 Ohm
        Voice Coil Inductance (Le)
        1 mH
        Resonant Frequency (Fs)
        55 Hz
        Mechanical Q (Qms)
        3.26
        Electromagnetic Q (Qes)
        0.51
        Total Q (Qts)
        0.44
        Diaphragm Mass Inc. Airload (Mms)
        12g
        Mechanical Compliance of Suspension (Cms)
        0.70 mm/N
        Surface Area of Cone (Sd)
        80 cm²
        Volume of Displacement (Vd)
        16 cm³
        BL Product (BL)
        7.0 Tm
        Compliance Equivalent Volume (Vas)
        6.4 L
        Maximum Linear Excursion (Xmax)
        2 mm
        # Mounting Holes
        4

        Show more
