        Product description FaitalPRO 6HX150-8P Bass-midwoofer Coaxial

        Precision 6" coaxial driver with integrated compression tweeter and 8-ohm impedance, delivering point-source accuracy and dynamic full-range performance in compact speaker systems.



        Highlights of the FaitalPRO 6HX150-8P Bass-midwoofer Coaxial

        • 6" (160mm) bass-midwoofer with centrally mounted 1" compression driver for true coaxial output
        • 8-ohm impedance for easy integration with standard amplifiers and crossover networks
        • Coherent point-source design ensures precise imaging and phase alignment
        • Wide frequency range and high efficiency for compact high-performance two-way enclosures



        Product details FaitalPRO 6HX150-8P Bass-midwoofer Coaxial

        FaitalPRO 6HX150-8P Bass-midwoofer Coaxial Full-range Coaxial Driver Unit



        The FaitalPRO 6HX150-8P is a 6" coaxial loudspeaker that combines a bass-midrange driver with a high-performance 1" compression driver for compact, coherent, full-range sound reproduction. Engineered for precision, its true coaxial design offers excellent time and phase alignment, ideal for studio monitors, compact PA systems, and premium custom loudspeakers. With an 8-ohm impedance and high sensitivity, the 6HX150-8P is compatible with a wide range of amplifier setups and crossover configurations. The robust ferrite motor provides strong cone control and stability under load, while the integrated HF unit extends the usable frequency response into the high treble range. Whether for stage monitoring or detailed reference listening, this coaxial unit ensures clarity, spatial accuracy, and rich tonal performance—all in a space-efficient form factor.

        Show more

        Specifications

        Article number
        6HX150-8P
        EAN
        0848864011660
        Woofer Type
        Bass-Midwoofer
        Nominal Diameter
        6''
        Power Handling (RMS)
        300 Watts
        Power Handling (max)
        30 Watts
        Impedance (Z)
        8 Ω
        Sensitivity (SPL at 1m / 2.83V)
        93 dB (LF) + 104 DB (HF)
        Frequency Response
        90-5.000 Hz (LF) + 1.500-18.000 Hz (HF)
        Voice Coil Diameter
        52 mm (LF) + 25 mm (HF)
        DC Resistance (Re)
        5.5 Ω (LF) + 6 Ω (HF)
        Voice Coil Inductance (Le)
        0.64 mH
        Resonant Frequency (Fs)
        88 Hz
        Mechanical Q (Qms)
        8.3
        Electromagnetic Q (Qes)
        0.35
        Total Q (Qts)
        0.34
        Diaphragm Mass Inc. Airload (Mms)
        14 g
        Moving Mass Of Diaphragm (Mmd)
        12.1 g
        Mechanical Compliance of Suspension (Cms)
        0.23 mm/N
        Surface Area of Cone (Sd)
        139.2 cm²
        BL Product (BL)
        12 N/A
        Compliance Equivalent Volume (Vas)
        6.3 dm³
        Maximum Linear Excursion (Xmax)
        4.35 mm
        Driver's Mechanical Losses (Rms)
        0.9 kg/s
        Voice Coil Wire Material
        cu (LF) m+ Al (HF)
        Voice Coil Former
        Glass Fiber (LF) + Kapton (HF)
        Magnet Material
        Neodymium
        Overall Outside Diameter
        186.5 mm
        Overall Depth
        95 mm
        Baffle Cutout Diameter
        147 mm
        Bolt Circle Diameter
        172 mm
        # Mounting Holes
        4
        Mounting Hole Diameter
        5.3 mm
