        3FE22-16F 3" Full-range Woofer 16 Ohm

        FaitalPRO 3FE22-16F 3" Full-range Woofer 16 Ohm

        €29,95

        4 In stock

        Add to cart

        FaitalPRO 3FE22-16F 3" Full-range Woofer 16 Ohm

        0 reviews
        0 from 5
        0 reviews
        5 stars
        0%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: FaitalPRO
        Show all Full-range woofer
        3" | 16 Ω
        3FE22-16F 3" Full-range Woofer 16 Ohm
        3FE22-16F 3" Full-range Woofer 16 Ohm
        3FE22-16F 3" Full-range Woofer 16 Ohm
        3FE22-16F 3" Full-range Woofer 16 Ohm
        3FE22-16F 3" Full-range Woofer 16 Ohm
        3FE22-16F 3" Full-range Woofer 16 Ohm
        € 24,75€ 29,95 4 In stock
        • -5% Purchase 4 for only € 28,45 per piece
        +-
        Add to cart

        Buy now, pay later

        • We ship to
        • Ordered now, shipped on Monday
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        3FE22-16F 3" Full-range Woofer 16 Ohm
        3FE22-16F 3" Full-range Woofer 16 Ohm
        3FE22-16F 3" Full-range Woofer 16 Ohm
        3FE22-16F 3" Full-range Woofer 16 Ohm
        3FE22-16F 3" Full-range Woofer 16 Ohm
        3FE22-16F 3" Full-range Woofer 16 Ohm

        Product description FaitalPRO 3FE22-16F Full-range Woofer

        Compact 3" full-range driver with 16-ohm impedance and neodymium magnet, designed for professional audio systems requiring clarity, efficiency, and space-saving installation.



        Highlights of the FaitalPRO 3FE22-16F Full-range Woofer

        • 83mm (3") full-range driver with 16-ohm impedance for broader amplifier compatibility
        • High sensitivity of 91dB (1W/1m) for dynamic output in small enclosures
        • Neodymium magnet assembly reduces weight and enhances performance
        • Wide frequency response from 100Hz to 20kHz for accurate full-range reproduction



        Product details FaitalPRO 3FE22-16F Full-range Woofer

        FaitalPRO 3FE22-16F Full-range Woofer Full-range Driver Unit



        The FaitalPRO 3FE22-16F is a high-performance 3-inch full-range driver optimized for use in compact and professional speaker systems. Featuring an 16-ohm impedance, this model provides increased flexibility for amplifier matching and system design. Its lightweight neodymium magnet structure helps maintain a low profile and reduced weight, making it ideal for portable and space-sensitive audio solutions. With a frequency response spanning 100Hz to 20kHz and a sensitivity rating of 91dB, the 3FE22-16F delivers balanced sound with clear mids and detailed highs. The treated paper cone and pressed steel basket offer a good combination of tonal neutrality and mechanical durability. Perfect for nearfield monitors, portable PA systems, line arrays, and DIY audio projects, the 3FE22-16F delivers reliable, high-quality sound in an exceptionally compact format.

        Show more

        Specifications

        Article number
        3FE22-16F
        EAN
        0848864011158
        Woofer Type
        Full Range Woofer
        Nominal Diameter
        3''
        Power Handling (RMS)
        20 Watts
        Power Handling (max)
        40 Watts
        Impedance (Z)
        16 Ω
        Sensitivity (SPL at 1m / 2.83V)
        91 dB
        Frequency Response
        100 - 20.000 Hz
        Voice Coil Diameter
        19 mm
        DC Resistance (Re)
        6.2 Ω
        Voice Coil Inductance (Le)
        0.15 mH
        Resonant Frequency (Fs)
        110 Hz
        Mechanical Q (Qms)
        5.0
        Electromagnetic Q (Qes)
        0.52
        Total Q (Qts)
        0.47
        Diaphragm Mass Inc. Airload (Mms)
        2.5 g
        Moving Mass Of Diaphragm (Mmd)
        2.3 g
        Mechanical Compliance of Suspension (Cms)
        0.84 mm/N
        Surface Area of Cone (Sd)
        33 cm²
        BL Product (BL)
        4.5 N/A
        Compliance Equivalent Volume (Vas)
        1.3 dm³
        Maximum Linear Excursion (Xmax)
        1.83 mm
        Driver's Mechanical Losses (Rms)
        0.3 kg/s
        Voice Coil Wire Material
        Aluminium
        Voice Coil Former
        Kapton
        Basket / Frame Material
        Steel
        Magnet Material
        Neodymium
        Overall Outside Diameter
        195.6 mm
        Overall Depth
        46 mm
        Baffle Cutout Diameter
        73.6 mm
        Bolt Circle Diameter
        92 mm
        Mounting Hole Diameter
        4.5 mm

        Show more
