        Product description FaitalPRO 12RS1066-8P Subwoofer

        The FaitalPRO 12RS1066 is a robust 12-inch subwoofer driver built for demanding professional sound reinforcement applications. With its powerful 1000 W AES rating and extended excursion capabilities, it's engineered to handle high SPL environments with consistency and control.



        Highlights of the FaitalPRO 12RS1066

        • Massive 1000 W AES power handling and up to 2000 W peak
        • 4" copper voice coil for enhanced thermal management and durability
        • High excursion capability with 12.45 mm Xmax
        • Durable NBR half-roll surround and aluminum demodulation ring for reduced distortion



        Product details FaitalPRO 12RS1066

        FaitalPRO 12RS1066 Subwoofer Loudspeaker Driver



        The FaitalPRO 12RS1066 is a high-performance 12-inch subwoofer tailored for applications requiring extended low-frequency response and high output power. It features a large 100 mm (4 in) copper voice coil on a glass fiber former, driven by a neodymium ring magnet system that combines compactness with powerful motor strength. Operating across a frequency range of 45 Hz to 2500 Hz, this driver suits both low-frequency and midbass roles in multi-way sound systems.

        Built with an aluminum basket and demodulation ring, the 12RS1066 is optimized to reduce thermal compression and distortion. The NBR half-roll surround supports linear cone movement, while the double spider configuration enhances mechanical stability during large excursions. With a sensitivity of 93 dB and an Xmax of 12.45 mm, this driver delivers controlled, deep bass reproduction, making it a go-to solution for professional PA systems, bass bins, and high-power speaker enclosures.

        Show more

        Specifications

        Article number
        12RS1066-8P
        EAN
        9509456516413
        Woofer Type
        Subwoofer
        Nominal Diameter
        12''
        Power Handling (RMS)
        1000 Watts
        Power Handling (max)
        2000 Watts
        Impedance (Z)
        8 Ω
        Sensitivity (SPL at 1m / 2.83V)
        93 dB
        Frequency Response
        45 - 2.500 Hz
        Voice Coil Diameter
        100 mm
        DC Resistance (Re)
        5 Ω
        Voice Coil Inductance (Le)
        1.35 mH
        Resonant Frequency (Fs)
        42 Hz
        Mechanical Q (Qms)
        13.9
        Electromagnetic Q (Qes)
        0.34
        Total Q (Qts)
        0.33
        Diaphragm Mass Inc. Airload (Mms)
        156.5 g
        Moving Mass Of Diaphragm (Mmd)
        144.0 g
        Mechanical Compliance of Suspension (Cms)
        0.09 mm/N
        Surface Area of Cone (Sd)
        496 cm²
        BL Product (BL)
        24.8 N/A
        Compliance Equivalent Volume (Vas)
        31.5 dm³
        Maximum Linear Excursion (Xmax)
        12.45 mm
        Driver's Mechanical Losses (Rms)
        3.0 kg/s
        Voice Coil Wire Material
        Cu
        Voice Coil Former
        Glass Fiber
        Basket / Frame Material
        Aluminium
        Magnet Material
        Neodymium
        Overall Outside Diameter
        316 mm
        Overall Depth
        176.5 mm
        Baffle Cutout Diameter
        282 mm
        Bolt Circle Diameter
        298.5 mm
        # Mounting Holes
        8
        Mounting Hole Diameter
        7.4 mm
