      Dayton Audio TCP115-8 4" Treated Paper Cone Woofer

      € 13,18€ 15,95 >10 In stock: delivery time 1-4 business days
      Bulk discount Enjoy these awesome discount deals
      • -5% Order 4 for only €15,15 per piece
      • 24h express shipping available
      • Low international shipping rates
      • Same day shipping
      • In-house technical support
      Do you have a question about this product?

      Do you have a question about this product?

      Our employee is happy to help you find the right product

      Product description

      With high excursion capabilities and low Fs, Dayton Audio's TCP115-8 can produce a surprising amount of bass for a 4" woofer. In addition to its low frequency performance, this driver also performs very well through the midrange, making this driver ideal for use in smaller 2-way designs.



      Highlights

      • Powerful motor for efficiency and compact enclosure
      • 1" diameter 4-layer voice coil improves power handling and low frequency response
      • Aluminum former keeps voice coil cool for high power handling
      • Extended pole piece creates symmetrical magnetic field for lower distortion
      • Cosmetic low-profile mounting flange looks good without flush mountin



      Product details

      Dayton Audio TCP115-8 4" Treated Paper Cone Woofer



      The TCP115-8 combines a large motor, 1" 4-layer voice coil, vented pole, and a sizable rubber surround to make use of its 4 mm of Xmax. This combination of features makes it a very versatile driver which can be used as a bass driver in a small 2-way system, center channel, or even portable Bluetooth speaker designs.

      Specifications

      Article number
      TCP115-8
      Woofer Series
      Specialty Drivers Series
      Woofer Type
      Midwoofer
      Nominal Diameter
      4"
      Power Handling (RMS)
      40 Watts
      Power Handling (max)
      80 Watts
      Impedance (Z)
      8 ohms
      Sensitivity
      81.9 dB 2.83V/1m
      Frequency Response
      55 to 6,000 Hz
      Voice Coil Diameter
      1"
      DC Resistance (Re)
      7.8 ohms
      Voice Coil Inductance (Le)
      1.9 mH
      Resonant Frequency (Fs)
      59.2 Hz
      Mechanical Q (Qms)
      2.3
      Electromagnetic Q (Qes)
      0.54
      Total Q (Qts)
      0.43
      Diaphragm Mass Inc. Airload (Mms)
      10.16g
      Mechanical Compliance of Suspension (Cms)
      0.71 mm/N
      Surface Area of Cone (Sd)
      50 cm²
      BL Product (BL)
      7.4 Tm
      Compliance Equivalent Volume (Vas)
      0.09 ft.³
      Maximum Linear Excursion (Xmax)
      4 mm
      Cone / Diaphragm Material
      Treated Paper
      Surround Material
      Rubber
      Voice Coil Wire Material
      CCA
      Voice Coil Former
      Aluminum
      Basket / Frame Material
      Steel
      Magnet Material
      Ferrite
      Overall Outside Diameter
      4.57"
      Overall Depth
      2.32"
      Baffle Cutout Diameter
      3.77"
      Bolt Circle Diameter
      4.25"
      # Mounting Holes
      4
      Sealed Volume
      0.03 ft.³
      Sealed F3
      116Hz
      Vented Volume
      0.10 ft.³
      Vented F3
      60 Hz

      Show more

      Reviews

      5 from 5Based on 18 reviews
      Review this product
      5 of 5
      The values ​​provided by the manufacturer do not seem correct to me. To me they don't sound as good in 3-liter reflex as the manufacturer suggests. You should go from 4 to 5.3 / 4 liters in my opinion, only then you will have really strong and deep bass, even if not perfectly accurate at all. Then they are extremely linear up to 2500 hz.
      By Sabato Foschillo on 19 April 2022
      4 of 5

      Replace on edifier tcn1000 with new tweeter and 12db 3200hz custom

      • +More bass and linearity. Middle freq smooth
      • -Any them now
      By Bafio66 on 4 March 2022
