    Dayton Audio RSS265HO-44 10" Reference HO DVC Subwoofer

    € 219,95 9 In stock: delivery time 1-4 business days
    The RSS265HO-44 10" High Output Reference Subwoofer from Dayton Audio is designed for high power handling and extremely low distortion. A small enclosure requirement allows it to be used in car audio and space limited home audio applications.... Show more
    Bulk discount Enjoy these awesome discount deals
    • -5% Order 4 for only €208,95 per piece
    • Shipping always fully insured and with track & trace
    • Low international shipping rates
    • Same day shipping*
    • In-house technical support

    Product description

    The RSS265HO-44 10" High Output Reference Subwoofer from Dayton Audio is designed for high power handling and extremely low distortion. A small enclosure requirement allows it to be used in car audio and space limited home audio applications.



    Highlights

    • Dual 4 ohm voice coils for many wiring options
    • Extensively vented motor eliminates compression and allows quiet excursion
    • Extra-thick black anodized aluminum cone for maximum rigidity
    • Triple shorting-ring motor for ultra-low distortion
    • Parameters optimized for small enclosures
    • Highest quality materials throughout for long-lasting performance



    Product details

    Dayton Audio RSS265HO-44 10" Reference HO DVC Subwoofer



    Dayton Audio's 10" RSS265HO-44 High Output Reference Series subwoofer is purpose-built for moving lots of air, extreme power handling, extremely low distortion... and it does it all with an extremely small enclosure requirement! The minimum airspace optimization of this driver makes it perfect for car audio automotive applications and limited space home audio applications.



    To minimize distortion, three copper short-circuit paths are built into the motor. This reduces second, third, and intermodulation distortion to levels only attained previously by expensive, exotic subwoofers. A side benefit is reduced energy storage and inductance, making the RSS265-HO-44 a very musical subwoofer. In fact, frequency response remains very flat up to 500 Hz.



    Additional features include: a heavy gauge black anodized aluminum cone that resists deformation from extreme air pressure levels found inside of small sealed enclosures, a fully ventilated motor for reduced power compression, a rigid cast aluminum frame for structural integrity, and a tough rubber surround that won't wear down over years of use. Dual 4-ohm voice coils allow for a wide array of wiring options.



    As with all Dayton Audio subwoofers, you receive a full 5-year warranty. Designed and engineered in the U.S.A.



    Specifications

    Article number
    RSS265HO-44
    Woofer Series
    Reference Series
    Woofer Type
    Subwoofer
    Nominal Diameter
    10"
    Power Handling (RMS)
    600 Watts
    Power Handling (max)
    1200 Watts
    Impedance
    4+4 ohms
    Sensitivity
    90.5 dB 2.83V/1m
    Frequency Response
    25 to 600 Hz
    Voice Coil Diameter
    2.58"
    DC Resistance (Re)
    1.6 ohms
    Voice Coil Inductance (Le)
    0.77 mH
    Resonant Frequency (Fs)
    27.6 Hz
    Mechanical Q (Qms)
    4.42
    Electromagnetic Q (Qes)
    0.50
    Total Q (Qts)
    0.45
    Diaphragm Mass Inc. Airload (Mms)
    161g
    Mechanical Compliance of Suspension (Cms)
    0.21 mm/N
    Surface Area of Cone (Sd)
    352.3 cm²
    BL Product (BL)
    9.39 Tm
    Compliance Equivalent Volume (Vas)
    1.23 ft.³
    Maximum Linear Excursion (Xmax)
    13.25 mm
    Cone / Diaphragm Material
    Aluminum
    Surround Material
    Rubber
    Dual Voice Coil
    Yes
    Basket / Frame Material
    Cast Aluminum
    Overall Outside Diameter
    10.5"
    Overall Depth
    5"
    Baffle Cutout Diameter
    9.25"
    Sealed Volume
    0.55 ft.³
    Sealed F3
    46 Hz
    Vented Volume
    1.5 ft.³
    Vented F3
    22 Hz
