        Dayton Audio RS52FN-8 2" Reference Fabric Dome Midrange 8 Ohm

        3 reviews
        Brand: Dayton Audio
        Show all Mid-range woofer
        2" | 8 Ω
        RS52FN-8 2" Reference Fabric Dome Midrange 8 Ohm
        RS52FN-8 2" Reference Fabric Dome Midrange 8 Ohm
        RS52FN-8 2" Reference Fabric Dome Midrange 8 Ohm
        RS52FN-8 2" Reference Fabric Dome Midrange 8 Ohm
        RS52FN-8 2" Reference Fabric Dome Midrange 8 Ohm
        RS52FN-8 2" Reference Fabric Dome Midrange 8 Ohm
        € 52,02€ 62,95 10+ In stock
        • -5% Order 4 for only € 59,80 per piece
        +-
        Add to cart

        Buy now, pay later

        • 24h express shipping available
        • Ordered now, shipped today
        • In-house techniscal support
        • 45 days worry-free returns
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        RS52FN-8 2" Reference Fabric Dome Midrange 8 Ohm
        RS52FN-8 2" Reference Fabric Dome Midrange 8 Ohm
        RS52FN-8 2" Reference Fabric Dome Midrange 8 Ohm
        RS52FN-8 2" Reference Fabric Dome Midrange 8 Ohm
        RS52FN-8 2" Reference Fabric Dome Midrange 8 Ohm
        RS52FN-8 2" Reference Fabric Dome Midrange 8 Ohm

        Product description

        The Dayton Audio Reference Series dome midrange delivers smooth and natural midrange performance with excellent off-axis response. High quality construction includes a cast aluminum faceplate, metal grill, vented former, and copper clad pole piece.



        Highlights

        • Large damped rear chamber for low resonance point
        • 2" damped fabric diaphragm for natural response and dispersion
        • Neodymium keeps size and weight to a minimum without sacrificing efficiency
        • Copper clad motor reduces distortion for transparent sound



        Product details

        Dayton Audio RS52FN-8 2" Reference Fabric Dome Midrange 8 Ohm



        The Dayton Audio Reference Series soft dome midrange delivers excellent off-axis response and midrange performance. Its 2" damped fabric diaphragm is linear throughout the midrange and lower treble, allowing it to provide a seamless transition to tweeters. The superior dispersion characteristics will eliminate suckouts and other problems that can occur in typical 2-way designs with large woofers. High quality construction includes a cast aluminum faceplate, metal grill, vented former, and copper clad pole piece. Great for use with other members of the Reference Series but will also work well with any high-performance drivers.

        Show more

        Specifications

        Article number
        RS52FN-8
        Woofer Series
        Reference Series
        Woofer Type
        Mid-dome
        Nominal Diameter
        2"
        Power Handling (RMS)
        60 watts
        Power Handling (max)
        120 watts
        Impedance (Z)
        8 ohms
        Sensitivity
        90.0 dB @ 2.83V/1m
        Frequency Response
        500 - 8,500 Hz
        Voice Coil Diameter
        2"
        DC Resistance (Re)
        5.7 ohms
        Voice Coil Inductance (Le)
        0.12 mH
        Resonant Frequency (Fs)
        394.3 Hz
        Mechanical Q (Qms)
        4.27
        Electromagnetic Q (Qes)
        1.39
        Total Q (Qts)
        1.05
        Surface Area of Cone (Sd)
        26.4 cm²
        Maximum Linear Excursion (Xmax)
        1mm
        Surround Material
        Cloth
        Voice Coil Wire Material
        Copper
        Voice Coil Former
        Aluminum
        Basket / Frame Material
        Cast Aluminum
        Magnet Material
        Neodymium
        Overall Outside Diameter
        5.12"
        Overall Depth
        2.24"
        Baffle Cutout Diameter
        3.94"
        # Mounting Holes
        6

        Show more

        Reviews

        3 reviews
        5 from 5Based on 3 reviews
        Review this product
        5 of 5
        Swapped for old midrange. This driver had much clearer sound. I am very pleased! (Made a 3D printed adapterplate to fit my speaker).
        By Gunnar A. on 20 May 2021
        5 of 5
        Very good sound; frequency response is very smooth and harmonic distortion low
        By Walter F. on 2 September 2020
