    Dayton Audio RS180-4 7" Reference Woofer 4 Ohm

    € 54,92€ 66,45 >10 In stock: delivery time 1-4 business days
    Bulk discount Enjoy these awesome discount deals
    • -5% Order 4 for only €63,13 per piece
    • Shipping always fully insured and with track & trace
    • Low international shipping rates
    • Same day shipping*
    • In-house technical support

    Product description

    The Dayton Audio Reference Series sets a new standard of value in high-performance loudspeaker drivers. Woofer features a black anodized cone, heavy-duty 6-hole cast frame, low-loss rubber surround, solid aluminum phase plug, and gold spring terminals.



    Highlights

    • 4 ohm impedance is perfect for series pairs in MTMs and center channel speakers
    • Excellent car audio midrange/midbass
    • High-end low-distortion motor with two shorting paths to reduce inductance



    Product details

    Dayton Audio RS180-4 7" Reference Woofer 4 Ohm

    The Dayton Audio Reference Series sets a new standard of value in high-performance loudspeaker drivers. Utilizing a low-distortion motor system with two short-circuit paths and a rigid aluminum cone, the Reference Series can outperform drivers that cost several times the price. Their low-distortion characteristics and high excursion capabilities provide exceptional clarity, detail, and dynamics. Woofer features a black anodized cone, heavy-duty 6-hole cast frame, low-loss rubber surround, solid aluminum phase plug, and gold terminals.

    Specifications

    Article number
    RS180-4
    Woofer Series
    Reference Series
    Woofer Type
    Midwoofer
    Nominal Diameter
    7"
    Power Handling (RMS)
    60 watts
    Power Handling (max)
    120 watts
    Impedance (Z)
    4 ohms
    Sensitivity
    89.2 dB @ 2.83V/1m
    Frequency Response
    39 - 3,600 Hz
    Voice Coil Diameter
    38 mm
    DC Resistance (Re)
    3.1 ohms
    Voice Coil Inductance (Le)
    0.45 mH @ 1 kHz
    Resonant Frequency (Fs)
    38.4 Hz
    Mechanical Q (Qms)
    2.13
    Electromagnetic Q (Qes)
    0.59
    Total Q (Qts)
    0.46
    Diaphragm Mass Inc. Airload (Mms)
    17.8g
    Mechanical Compliance of Suspension (Cms)
    0.97 mm/N
    Surface Area of Cone (Sd)
    124.7 cm²
    Volume of Displacement (Vd)
    74.8 cm³
    BL Product (BL)
    4.71 Tm
    Compliance Equivalent Volume (Vas)
    21.2 liters
    Maximum Linear Excursion (Xmax)
    6.0 mm
    Cone / Diaphragm Material
    Black Anodized Aluminum Cone
    Surround Material
    Rubber
    Voice Coil Wire Material
    Copper
    Voice Coil Former
    Aluminum
    Basket / Frame Material
    Cast Aluminum
    Magnet Material
    Ferrite
    Overall Outside Diameter
    180.5 mm
    Overall Depth
    82 mm
    Baffle Cutout Diameter
    146 mm
    # Mounting Holes
    6
    Sealed Volume
    0.42 ft.³
    Sealed F3
    69 Hz
    Vented Volume
    1.33 ft.³
    Vented F3
    35 Hz
