      Dayton Audio RS125-4 5" Reference Woofer 4 Ohm

      € 41,28€ 49,95 1 In stock: delivery time 1-4 business days
      Bulk discount Enjoy these awesome discount deals
      • -5% Order 4 for only €47,45 per piece
      • 24h express shipping available
      • Low international shipping rates
      • Same day shipping
      • In-house technical support
      Do you have a question about this product?

      Do you have a question about this product?

      Our employee is happy to help you find the right product

      Product description

      The Dayton Audio Reference Series sets a new standard of value in high-performance loudspeaker drivers. Woofer features a black anodized cone, heavy-duty 6-hole cast frame, low-loss rubber surround, solid aluminum phase plug, and gold terminals.



      Highlights

      • 4 ohm impedance is perfect for series pairs in MTMs and center channel speakers
      • Excellent car audio midrange/midbass
      • High-end low-distortion motor with two shorting paths to reduce inductance



      Product details

      Dayton Audio RS125-4 5" Reference Woofer 4 Ohm

      The Dayton Audio Reference Series sets a new standard of value in high-performance loudspeaker drivers. Utilizing a low-distortion motor system with two short-circuit paths and a rigid aluminum cone, the Reference Series can outperform drivers that cost several times the price. Their low-distortion characteristics and high excursion capabilities provide exceptional clarity, detail, and dynamics. Woofer features a black anodized cone, heavy-duty 6-hole cast frame, low-loss rubber surround, solid aluminum phase plug, and gold terminals.

      Specifications

      Article number
      RS125-4
      Woofer Series
      Reference Series
      Woofer Type
      Midwoofer
      Nominal Diameter
      5"
      Power Handling (RMS)
      30 watts
      Power Handling (max)
      60 watts
      Impedance (Z)
      4 ohms
      Sensitivity
      89.9 dB @ 2.83V/1m
      Frequency Response
      65 - 5,400 Hz
      Voice Coil Diameter
      25 mm
      DC Resistance (Re)
      2.9 ohms
      Voice Coil Inductance (Le)
      0.28 mH @ 1 kHz
      Resonant Frequency (Fs)
      57.2 Hz
      Mechanical Q (Qms)
      2.04
      Electromagnetic Q (Qes)
      0.45
      Total Q (Qts)
      0.37
      Diaphragm Mass Inc. Airload (Mms)
      5.7g
      Mechanical Compliance of Suspension (Cms)
      1.35 mm/N
      Surface Area of Cone (Sd)
      52.8 cm²
      Volume of Displacement (Vd)
      21.1 cm³
      BL Product (BL)
      3.63 Tm
      Compliance Equivalent Volume (Vas)
      5.29 liters
      Maximum Linear Excursion (Xmax)
      4.0 mm
      Cone / Diaphragm Material
      Black Anodized Aluminum Cone
      Surround Material
      Rubber
      Voice Coil Wire Material
      Copper
      Voice Coil Former
      Aluminum
      Basket / Frame Material
      Cast Aluminum
      Magnet Material
      Ferrite
      Overall Outside Diameter
      125.5 mm
      Overall Depth
      54.2 mm
      Baffle Cutout Diameter
      94 mm
      # Mounting Holes
      6
      Sealed Volume
      0.12 ft.³
      Sealed F3
      103 Hz
      Vented Volume
      0.27 ft.³
      Vented F3
      51 Hz

      Show more

      Reviews

      5 from 5Based on 3 reviews
      Review this product
      5 of 5
      I use this speaker in a 3-way floorstander, with cross-over freqs of 150 and 3000 Hz. It has a separate chamber of 1,7 ltr and sounds perfect. I use it with active xover 48 dB/oct Linkwitz Riley (DSP Adau 1701) even low as 120,100 and 80 Hz for a try, sounds very good. I can recommend this one.
      By Martin H. on 13 October 2020
      5 of 5
      Hoogwaardig product voor de prijs. Heb er eentje in combinatie met een dayton 6ohm tweeter in een bass-reflex doos met een 30cm hoog en 18cm wijd op de voorkant. Klinkt zeer goed. Schijnbaar minder efficiënt dan zijn grotere tegenhangers, maar heeft dan weer andere voordelen (i.e. Crossover kan op hogere frequencies gebeuren tov deze). Voldoende voor een bureau/kleine living van 4/5m diep/breed.
      By Laurens VC on 15 June 2020
