    Dayton Audio PS95-8 3-1/2" Point Source Full Range Driver 8 Ohm

    € 26,45 Out of stock: delivery time is 1 week
    Dayton Audio's PS95-8 3-1/2" point source full range driver delivers the full spectrum of sound – including clear, natural highs – with excellent detail and articulation. No tweeter required!... Show more
    Bulk discount Enjoy these awesome discount deals
    • -5% Order 4 for only €25,13 per piece
    • Low international shipping rates
    • Same day shipping*
    • Pay with PayPal, Creditcard, and more
    • In-house technical support

    Product description

    Dayton Audio's PS95-8 3-1/2" point source full range driver delivers the full spectrum of sound – including clear, natural highs – with excellent detail and articulation. No tweeter required!



    Highlights

    • Copper pole cap in motor assembly reduces inductance and distortion
    • Detailed, natural sounding full-range audio performance without distortion
    • Classy copper-anodized phase plug spreads dispersion and avoids resonance
    • Low-mass voice coil and paper cone produce detailed, non-fatiguing sound
    • Non-resonant cast frame enhances clarity and dynamics



    Product details

    Dayton Audio PS95-8 3-1/2" Point Source Full Range Driver 8 Ohm

    The newest addition to Dayton Audio's successful family of Point Source full-range drivers, the PS95-8 model features a lightweight, curved-profile paper cone made of 100% natural fibers, for dynamic and articulate sound that extends from a punchy, detailed bass to the highest treble. The compact 3-1/2" size enables great sonic performance in small satellite speakers on the desktop, or in narrow "needle"-style tower cabinets for filling a larger room.



    The copper-anodized aluminum phase plug of the PS95-8 is more than just beautiful – it provides enhanced dispersion and eliminates the resonance from a conventional dust cap. And the optimized, high-strength ferrite magnet structure features a copper pole cap that reduces resolution-sapping inductance and lowers distortion. Our smallest Point Source series full-range driver isn't small on engineering, or performance!

    Specifications

    Article number
    PS95-8
    Woofer Series
    Point Source Series
    Woofer Type
    Full-Range
    Nominal Diameter
    3.50"
    Power Handling (RMS)
    10 watts
    Power Handling (max)
    20 watts
    Impedance
    8 ohms
    Sensitivity
    85.56 dB @ 2.83V/1m
    Frequency Response
    110 - 20,000 Hz
    Voice Coil Diameter
    20 mm
    DC Resistance (Re)
    7.1 ohms
    Voice Coil Inductance (Le)
    0.63 mH @ 1 kHz
    Resonant Frequency (Fs)
    119.8 Hz
    Mechanical Q (Qms)
    7.33
    Electromagnetic Q (Qes)
    0.80
    Total Q (Qts)
    0.72
    Diaphragm Mass Inc. Airload (Mms)
    2.2g
    Mechanical Compliance of Suspension (Cms)
    0.79 mm/N
    Surface Area of Cone (Sd)
    28.3 cm²
    Volume of Displacement (Vd)
    7.08 cm³
    BL Product (BL)
    3.83 Tm
    Compliance Equivalent Volume (Vas)
    0.94 liters
    Maximum Linear Excursion (Xmax)
    2.5 mm
    Cone / Diaphragm Material
    Polypropylene
    Surround Material
    Rubber
    Voice Coil Wire Material
    Copper
    Voice Coil Former
    Slit Kapton
    Basket / Frame Material
    Cast Aluminum
    Magnet Material
    Ferrite
    Overall Outside Diameter
    76.8 mm
    Overall Depth
    52.3 mm
    Baffle Cutout Diameter
    69.8 mm
    # Mounting Holes
    4

    Reviews

    5 from 5Based on 20 reviews
    Review this product
    5 van 5
    Amazing value for money and perfect for a cheap DIY project, tweeters aren't necessarily needed with these
    Sound is great and I was really surprised at how much excursion they can handle.
    Buildquailty is amazing for that price!
    By GIZMO320 on 24 January 2021
    5 van 5
    I have used these woofers for concrete enclosure speaker boxes and have connect to Logitech powered subwoofer, so I'm satisfied with performance. I'm not an audiophile, but I wanted better audio quality than I had before, and have stylish work desk. Sadly, I have to later remake concrete speakers, as mixing ratios are important. Speakers have different greyness and wood baffle could be used from harder wood.
    By A. J. on 18 December 2020
