      Dayton Audio PA460-8 18" Pro Woofer

      € 181,78€ 219,95 7 In stock: delivery time 1-4 business days
      Bulk discount Enjoy these awesome discount deals
      • -5% Order 4 for only €208,95 per piece
      • 24h express shipping available
      • Low international shipping rates
      • Same day shipping
      • In-house technical support
      Do you have a question about this product?

      Do you have a question about this product?

      Our employee is happy to help you find the right product

      Product description

      Dayton Audio PA Series Pro Woofers are a great upgrade for musical instrument or sound reinforcement cabinets, and also excel in custom-built speaker systems.



      Highlights

      • Strong, low-mass carbon fiber impregnated paper cone
      • I-beam rolled edge 1.5 mm steel frame
      • Low distortion motor system w/copper cap
      • Powerful 80 oz. ceramic ferrite magnet
      • Vented pole piece/vented voice coil gap improve thermal management
      • Black motor parts and black polyimide voice coil former dissipate heat
      • Bumped back plate for unrestricted excursion



      Product details

      Dayton Audio PA460-8 18" Pro Woofer



      Dayton Audio PA Series Pro Woofers are a great upgrade for musical instrument or sound reinforcement cabinets, and also excel in custom-built speaker systems. High power handling, smooth response, low distortion, deep punchy bass, and rugged reliability are the features that set PA Series woofers apart from other drivers – premium performance, but value priced.



      Specifications

      Article number
      PA460-8
      Woofer Series
      Pro Audio Series
      Woofer Type
      Midwoofer
      Nominal Diameter
      18"
      Power Handling (RMS)
      500 watts
      Power Handling (max)
      1,000 watts
      Impedance (Z)
      8 ohms
      Sensitivity
      97.8 dB @ 2.83V/1m
      Frequency Response
      26 - 2,000 Hz
      Voice Coil Diameter
      76 mm
      Magnet Weight
      80 oz.
      DC Resistance (Re)
      5.6 ohms
      Voice Coil Inductance (Le)
      3.9 mH
      Resonant Frequency (Fs)
      28.3 Hz
      Mechanical Q (Qms)
      11.2
      Electromagnetic Q (Qes)
      0.34
      Total Q (Qts)
      0.33
      Diaphragm Mass Inc. Airload (Mms)
      171g
      Mechanical Compliance of Suspension (Cms)
      0.19 mm/N
      Surface Area of Cone (Sd)
      1,241.1 cm²
      Volume of Displacement (Vd)
      746.5 cm³
      BL Product (BL)
      22.3 Tm
      Compliance Equivalent Volume (Vas)
      402 liters
      Maximum Linear Excursion (Xmax)
      6.0 mm
      Cone / Diaphragm Material
      Paper / Carbon Fiber Cone
      Surround Material
      Cloth
      Voice Coil Wire Material
      Copper
      Voice Coil Former
      Kapton® / Polyimide
      Basket / Frame Material
      Steel
      Magnet Material
      Ferrite
      Overall Outside Diameter
      460 mm
      Overall Depth
      198 mm
      Baffle Cutout Diameter
      425 mm
      # Mounting Holes
      8
      Sealed Volume
      2.73 ft.³
      Sealed F3
      72 Hz
      Vented Volume
      5.68 ft.³
      Vented F3
      47 Hz

      Show more

      Reviews

      5 from 5Based on 2 reviews
      Review this product
      5 of 5
      I've now built four VBSS-subwoofers using these and they're great!
      By Kim A. on 15 October 2020
      5 of 5
      No description was given
      By Per G. on 14 October 2019
