        ND20FB-4 Dome Tweeter

        ND20FB-4 Dome Tweeter

        €15,95

        Dayton Audio ND20FB-4 Dome Tweeter

        7 reviews
        5 from 5
        7 reviews
        5 stars
        100%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        € 13,18€ 15,95 10+ In stock
        • -5% Purchase 4 for only € 15,15 per piece

        Buy now, pay later

        • We ship to
        • Ordered now, shipped tomorrow
        • Five-year warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        Product description

        This versatile tweeter is a huge step above the average "budget" tweeter. It has the sensitivity, smoothness, and power handling to individually do a two-way with most small woofers.



        Highlights

        • Compact neodymium motors have low stray field
        • Ferrofluid enhances power handling and helps damp resonance
        • Rear-mount design minimizes housing size
        • Center-to-center spacing as low as 1-1/2"
        • Great top-end air and sparkle



        Product details

        Dayton Audio ND20FB-4 Rear-Mount 3/4" Neodymium Dome Tweeter



        Don't let the low price fool you! This versatile tweeter is a huge step above the average "budget" tweeter. Conceived with line array thoughts in mind, it is finally possible to achieve the inter-driver spacing needed to minimize comb filtering out to nearly 20 kHz. But its uses don't stop at line arrays-- it has the sensitivity, smoothness, and power handling to individually do a two-way with most small woofers. Or, use it in an A-pillar in your car as a great inexpensive component tweeter. Give them a try for your next budget or micro speaker-- you will be pleasantly surprised!

        Show more

        Specifications

        Article number
        ND20FB-4
        Tweeter Type
        Soft Dome
        Tweeter Series
        ND Series
        Cone / Dome Diameter
        19 mm | 3/4"
        Power Handling (RMS)
        15 Watts
        Impedance (Z)
        4 Ω
        Sensitivity (SPL at 1m / 2.83V)
        93 dB
        Frequency Response
        3,500 to 25,000 Hz
        Resonant Frequency (Fs)
        2072 Hz
        DC Resistance (Re)
        3.20 ohms
        Voice Coil Inductance (Le)
        0.03 mH
        Mechanical Q (Qms)
        2.08
        Electromagnetic Q (Qes)
        3.74
        Total Q (Qts)
        1.33
        Overall Outside Diameter
        1.54" x 1.54"
        Cutout Diameter
        1.54" x 1.54"
        Depth
        0.75"

        Show more
