Dayton Audio ND16FA-6 5/8'' Neodymium Dome Tweeter

4 reviews

Brand: Dayton Audio

Show all Tweeters

Compare

5/8" | 6 Ω

€ 9,05€ 10,95 >10 In stock: delivery time 1-4 business days

24h express shipping available
Low international shipping rates
Same day shipping
In-house technical support

Do you have a question about this product?

Our employee is happy to help you find the right product

Product description

Don't let the low price fool you! This versatile tweeter is a huge step above the average "budget" tweeter.

Highlights

Unique front pressfit, flush-mount design
Center-to-center spacing as low as 1-3/8"
Extended response with superior off-axis dispersion
Compact neodymium motor is effectively self-shielded
Ferrofluid enhances power handling and helps damp resonance

Product details

Dayton Audio ND16FA-6 5/8" Neodymium Dome Tweeter

Don't let the low price fool you! This versatile tweeter is a huge step above the average "budget" tweeter. Conceived with line array thoughts in mind, it is finally possible to achieve the inter-driver spacing needed to minimize comb filtering out to nearly 20 kHz. But their uses don't stop at line arrays-- they have the sensitivity, smoothness, and power handling to individually do a two-way with most small woofers. Give them a try for your next budget or micro speaker-- you will be pleasantly surprised!

Specifications

Article number: ND16FA-6
Tweeter Type: Soft Dome
Tweeter Series: ND Series
Cone / Dome Diameter: 16 mm | 5/8"
Power Handling (RMS): 10 Watts
Impedance (Z): 6 Ω
Sensitivity: 89 dB 1W/1m
Frequency Response: 3,500 to 27,000 Hz
Resonant Frequency (Fs): 2,283 Hz
DC Resistance (Re): 5.00 ohms
Voice Coil Inductance (Le): 0.05 mH
Overall Outside Diameter: 1.28"
Cutout Diameter: 1"
Depth: 0.57"

Data sheet

Reviews

4 reviews

5 from 5Based on 4 reviews

Review this product

5 of 5

I used two of these tweeters with two Dayton audio tcp115-4 and a crossover frequency around 4400Hz (look for "Dayton 4" and you'll find a scheme of the crossover I got the inspiration from). The size was perfect for me as I had very little space to fit them, and the sound is crystal clear and enjoyable. Considering price and size I am really satisfied.

By Compact but great sounding on 9 December 2020

5 of 5

This is a very good tweeter with crystal clear sound.

By NIKOS K. on 10 September 2018
