        DSA175-8 6-1/2" Designer Series Aluminum Cone Woofer

        DSA175-8 6-1/2" Designer Series Aluminum Cone Woofer

        €64,95

        Dayton Audio DSA175-8 6-1/2" Designer Series Aluminum Cone Woofer

        6 reviews
        5 from 5
        6 reviews
        5 stars
        100%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        € 53,68€ 64,95 10+ In stock
        • -5% Purchase 4 for only € 61,70 per piece

        Buy now, pay later

        • We ship to
        • Same day shipping
        • Five-year warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        Product description

        Although it's true that the Dayton Audio Designer Series DSA175-8 is a nice looking and well thought-out 6-1/2" woofer, its ability to handle full rated power down to 39 Hz without exceeding Xmax is very impressive!



        Highlights

        • Cosmetic frame with low profile lip, designed for front mounting—no countersinking required!
        • Low distortion motor system with copper shorting ring
        • Black anodized aluminum cone, half roll rubber surround for durability and accurate reproduction
        • Smooth frequency response and linear roll-off simplify filter design
        • Vented pole piece for minimized power compression and maximized reliability
        • Retains the same "family look" as the popular Dayton Audio DVC Series subwoofers and passive radiators
        • Generous Xmax capability encourages use of moderate bass boost to tailor the response



        Product details

        Dayton Audio DSA175-8 6-1/2" Designer Series Aluminum Cone Woofer



        The Designer Series by Dayton Audio was developed specifically with the speaker designer in mind. It is an affordable, attractive line of drivers that puts performance first. Careful engineering ensures that each speaker in the series is capable of handling full rated power at the lowest possible frequencies — without exceeding Xmax.



        These speakers combine useful performance parameters with elegant style. Carefully optimized to provide superb audio reproduction when incorporated into a wide variety of enclosures and alignments, the Designer Series transducers put a beautiful face on audiophile excellence.

        Show more

        Specifications

        Article number
        DSA175-8
        Woofer Series
        Designer Series
        Woofer Type
        Midwoofer
        Nominal Diameter
        6.50"
        Power Handling (RMS)
        70 watts
        Power Handling (max)
        140 watts
        Impedance (Z)
        8 ohms
        Sensitivity (SPL at 1m / 2.83V)
        88.1 dB
        Frequency Response
        38 - 7,500 Hz
        Voice Coil Diameter
        35.5 mm
        Magnet Weight
        33 oz.
        DC Resistance (Re)
        5.8 ohms
        Voice Coil Inductance (Le)
        0.85 mH @ 1 kHz
        Resonant Frequency (Fs)
        38.4 Hz
        Mechanical Q (Qms)
        1.66
        Electromagnetic Q (Qes)
        0.35
        Total Q (Qts)
        0.29
        Diaphragm Mass Inc. Airload (Mms)
        24.2g
        Mechanical Compliance of Suspension (Cms)
        0.71 mm/N
        Surface Area of Cone (Sd)
        128.7 cm²
        Volume of Displacement (Vd)
        67.6 cm³
        BL Product (BL)
        9.75 Tm
        Compliance Equivalent Volume (Vas)
        18.7 liters
        Maximum Linear Excursion (Xmax)
        5.3 mm
        Cone / Diaphragm Material
        Aluminum Cone
        Surround Material
        Rubber
        Voice Coil Wire Material
        Copper
        Voice Coil Former
        Aluminum
        Basket / Frame Material
        Steel
        Magnet Material
        Ferrite
        Overall Outside Diameter
        175.6 mm
        Overall Depth
        80.6 mm
        Baffle Cutout Diameter
        144 mm
        # Mounting Holes
        5
        Sealed Volume
        0.17 ft.³
        Sealed F3
        112 Hz
        Vented Volume
        0.19 ft.³
        Vented F3
        71 Hz

        Show more

        5 of 5
        Great woofer, very clear sound
        By Heido Rebane on 31 March 2022
        5 of 5
        Es wurde keine Beschreibung gegeben.
        By Martin I. on 7 April 2021
