Dayton Audio DC28FS-8 1-1/8" Silk Dome Shielded Tweeter

3 reviews

Brand: Dayton Audio

Show all Tweeters

Compare

1⅛" | 8 Ω

DC28FS-8 1-1/8" Silk Dome Shielded Tweeter

€ 26,82€ 32,45 7 In stock: delivery time 1-4 business days

24h express shipping available
Low international shipping rates
Same day shipping
In-house technical support

Do you have a question about this product?

Our employee is happy to help you find the right product

Product description

Shielded version of the famous Dayton Audio Silk Dome Tweeter. 1-1/8" silk dome with ferrofluid cooling and fully shielded motor structure.

Highlights

Offers smooth and detailed high frequency performance
Magnetically shielded
Ferrofluid cooled voice coil

Product details

Dayton Audio DC28FS-8 1-1/8" Silk Dome Shielded Tweeter

The shielded version of the famous Dayton Audio Silk Dome, this tweeter offers the same performance but in a CRT-safe design. Features a 1-1/8" silk dome with a ferrofluid cooled voice coil for superior damping. Compare it to drivers costing $30 to $40 more! Recommended for crossover points as low as 1,800 Hz, making it ideal for most 2-way speaker designs. 5 year warranty.

Specifications: • Power handling: 50 watts RMS/100 watts max • VCdia: 1.14" • Le: 0.09 mH • Impedance: 8 ohms • Re: 5.6 ohms • Frequency range: 1,600-20,000 Hz • Fs: 813 Hz • SPL: 89 dB 1W/1m • Qms: 1.97 • Qes: 1.6 • Qts: 0.88 • Dimensions: Overall diameter: 4.33", Cutout diameter: 3.07", Depth: 1.42".

Specifications

Article number: DC28FS-8
Tweeter Type: Soft Dome
Tweeter Series: Classic Series
Cone / Dome Diameter: 25 mm | 1"
Power Handling (RMS): 50 Watts
Impedance (Z): 8 Ω
Sensitivity: 89 dB 1W/1m
Frequency Response: 1,600 to 20,000 Hz
Resonant Frequency (Fs): 905 Hz
DC Resistance (Re): 5.40 ohms
Voice Coil Inductance (Le): 1.58 mH
Mechanical Q (Qms): 2.21
Electromagnetic Q (Qes): 1.73
Total Q (Qts): 0.97
Overall Outside Diameter: 4.33"
Cutout Diameter: 3.07"
Depth: 1.42"

Data sheet

Reviews

3 reviews

5 from 5Based on 3 reviews

Review this product

5 of 5

in accordance with expectations. They work very well no problem

By MAIRE C. on 21 November 2019

5 of 5

Wist niet zo goed welke tweeter te nemen omdat het aanbod groot was. Ik heb me gebaseerd op de reviews van anderen over deze tweeter. En ik moet zeggen klinkt geweldig goed, klinkt crispy. Echt een aanrader.

By Dieter on 6 June 2019
