        M142P-6 Mid-range woofer

        BlieSMa M142P-6 Mid-range woofer

        €1.049,95

        4 In stock

        Add to cart

        BlieSMa M142P-6 Mid-range woofer

        0 reviews
        0 from 5
        0 reviews
        5 stars
        0%
        4 stars
        0%
        3 stars
        0%
        2 stars
        0%
        1 star
        0%
        View all reviews
        Brand: BlieSMa
        Show all Mid-range woofer
        5.5'' | 6 Ω
        M142P-6 Mid-range woofer
        M142P-6 Mid-range woofer
        M142P-6 Mid-range woofer
        M142P-6 Mid-range woofer
        M142P-6 Mid-range woofer
        M142P-6 Mid-range woofer
        M142P-6 Mid-range woofer
        M142P-6 Mid-range woofer
        M142P-6 Mid-range woofer
        M142P-6 Mid-range woofer
        M142P-6 Mid-range woofer
        M142P-6 Mid-range woofer
        M142P-6 Mid-range woofer
        M142P-6 Mid-range woofer
        € 867,73€ 1.049,95 4 In stock
        +-
        Add to cart

        Buy now, pay later

        • We ship to
        • Same day shipping
        • At least two years warranty
        • 45-day cooling-off period to return
        • Customer rating:
        Request quotation
        Do you have a question about this product?

        Do you have a question about this product?

        Our employee is happy to help you find the right product

        M142P-6 Mid-range woofer
        M142P-6 Mid-range woofer
        M142P-6 Mid-range woofer
        M142P-6 Mid-range woofer
        M142P-6 Mid-range woofer
        M142P-6 Mid-range woofer
        M142P-6 Mid-range woofer
        M142P-6 Mid-range woofer
        M142P-6 Mid-range woofer
        M142P-6 Mid-range woofer
        M142P-6 Mid-range woofer
        M142P-6 Mid-range woofer
        M142P-6 Mid-range woofer
        M142P-6 Mid-range woofer
        M142P-6 Mid-range woofer
        M142P-6 Mid-range woofer

        Product description BlieSMa M142P-6 Mid-range woofer

        Highlights

        • Single-layer ribbon CCAW voice coil for lower inductance
        • Thick aluminium powder coated basket
        • Underhung voice coil wound on titanium former
        • Gold plated wire terminals
        • 137 mm voice coil for low thermal compression
        • Recommended frequency range 180 Hz - 2,2 kHz
        • Surround hidden in basket rim allows significant reduction of mounting diameter
        • Natural silk surround and cotton spider from Dr. Kurt Müller GmbH & Co. for higher midrange resolution
        • Ring magnet system with large rear opening reduces backside reflections and improves dipole operation



        Product details

        BlieSMa M142P-6 Mid-range woofer


        142 mm paper dome. Ring magnet system with large rear opening reduces backside reflections and improves dipole operation. Extremely low moving mass for better transient response and higher efficiency. Fully saturated neodymium motor with copper sleeve for low non linear and modulation distortion.

        Show more

        Specifications

        Article number
        M142P-6
        EAN
        08785256847198
        Woofer Type
        Mid-range Woofer
        Power Handling (RMS)
        N/A Watts
        Impedance (Z)
        6 Ω
        Sensitivity (SPL at 1m / 2.83V)
        94 dB
        Frequency Response
        180-2.200 kHz
        Voice Coil Diameter
        137 mm
        DC Resistance (Re)
        5.4 Ω
        Voice Coil Inductance (Le)
        0.03 mH
        Resonant Frequency (Fs)
        63 Hz
        Mechanical Q (Qms)
        7.3
        Electromagnetic Q (Qes)
        0.32
        Total Q (Qts)
        0.31
        Diaphragm Mass Inc. Airload (Mms)
        11.7 g
        Surface Area of Cone (Sd)
        180.3 cm²
        BL Product (BL)
        8.8 Tm
        Compliance Equivalent Volume (Vas)
        24.6 Liters
        Maximum Linear Excursion (Xmax)
        +/- 1.85 mm
        Driver's Mechanical Losses (Rms)
        0.54 kg/s
        Voice Coil Former
        Titanium
        Basket / Frame Material
        Aluminium powder coated
        Magnet Material
        Neodymium
        Overall Outside Diameter
        180 mm
        Overall Depth
        62 mm
        Baffle Cutout Diameter
        158 mm
        Bolt Circle Diameter
        169 mm
        # Mounting Holes
        6
        Mounting Hole Diameter
        4.5 mm
